6.5ton Excavator

Name: 6.5ton Excavator
Brand: XCMG
SKU: 141324678
Availability: InStock

US$ 18,000 - 660,000 MOQ: 1 Unit

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

XCMG

Model Number:

XE65

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port of China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name XCMG

Model Number XE65

Condition New

Moving Type Crawler Excavator

Maximum Digging Height 5630mm

Maximum Digging Depth 3830mm

Specifications

1.Operating weight:6200kg;
2.Bucket capacity: 0.25;
3.Engine:4TNV94L;

Specifications

Model		Unit	XE65D
Operating weight		kg	6200
Standard bucket capacity		m³	0.09-0.25
Engine	Engine Model	/	4TNV94L
	Direct injection	/	√
	Four strokes	/	√
	Water cooling	/	√
	No. of cylinders	/	4
	Rated power/speed	kw/rpm	39.8/2200
	Max. torque/speed	N.m	214/1100
	Displacement	L	3.054
Main Performance	Travel speed	km/h	4.2/2.2
	Swing speed	r/min	11
	Ground pressure	kPa	32.5
	Max.Bucket digging force	kN	48.3
	Max.arm crowd force	kN	32.5
	Max.traction force	kN	50.5
	Rate flow of main pump	L/min	138/143
	Max pressure of prime relief valve	MPa	24.5
	Max pressure of travel system	MPa	22
	Max pressure of swing system	MPa	23
	Max pressure of pilot system	MPa	2.6
Oil Capacity	Fuel tank capacity	L	110
	Hydraulic tank capacity	L	85
	Engine lubrication	L	12
Dimentions	Overall length	mm	5860
	Overall width	mm	2000/1920
	Overall height	mm	2585
	Overall width of upperstructure	mm	1780
	Track length	mm	2616
	Overall width of undercarriage	mm	2000
	Dozer black(width/height)	mm	2000×363/1920×340
	Tumbler distance	mm	2053
	Clearance under counter weight	mm	694
	Ground clearance	mm	369
	Min.tail swing radius	mm	1660
Work Scope	Max. digging height	mm	5630
	Max. dumping height	mm	3945
	Max. digging depth	mm	3830
	Max. vertical wall digging depth	mm	2680
	Max. digging reach	mm	6130
