CANMAX Truck Mounted Cocrete Pump HDT5280THB 37/4

Name: CANMAX Truck Mounted Cocrete Pump HDT5280THB 37/4
Brand: CANMAX
SKU: 141324440
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Place of Origin:

Shanghai, China

Brand Name:

CANMAX

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port of China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shanghai, China

Brand Name CANMAX

Model Number HDT5280THB 37/4

Specifications

1 CANMAX Truck mounted cocrete pump HDT5280THB 37/4
2.Germany DEUTZ diesel engine,REXROTH oil pump
3 American VICKERS valve

CANMAX Truck mounted cocrete pump HDT5280THB 37/4

Pump Truck 56m		Unit	Parameters
Pump Truck 56m		Unit	HDT5280THB 37/4
Main technical parameters in working condition	Theoretical Productivity	m3/h	125
	Pumping Capacity Index	MPa.* m3/h	586
	Max. Concrete Pressure	Mpa	8.5
	Hopper Capacity	L	700
	Feeding Height	mm	1370
	Model of Distributing Valve		S pipe valve
	Max. Distributing Radius	m	32.6
	Max. Distributing Height	m	36.6
	Max. Distributing Depth	m	25
	Height of Distributing Boom When Stretched	mm	8450
	Distance between Front Landing Legs	mm	6200
	Distance between Rear Landing Legs	mm	6600
	Distance between Front and Rear Landing Legs	mm	7100
	Diameter of Delivery Pipe	mm	125
	Length of Tail Hose	m	4
	Rotary Range of Distributing Boom		370°
	Number of Boom Sections		4
	Rotary Angle of Each Boom Section		100/180/ 180/240°
	Close-control Distance	m	33
	Remote-control Distance	m	200
Main technical parameters in driving condition	Max. Traveling Speed	km/h	85
	Min. Turning Radius	mm	7600
	Brake Distance	m	7
	Approach Angle		24°
	Departure Angle		15°
	Chassis Model		CXZ51Q JAPAN ISUZU
	Chassis Model		CHINA HOWO
	Wheel Base between the First and the Second Axle	mm	4595
	Wheel Base between the Second and the Third Axle	mm	1310
	Wheel Base between the Third and the Fourth Axle	mm
	Front Tread	mm	2065
	Rear Tread	mm	1855
	Max. Engine Power	kw	286 (1800r/min)
	Max Engine Torque	N.m	1079 (1100r/min)
	Max. Grade Ability	%	37
	Fuel Consumption Limit	L/100km	34
	Overall Dimension (length×width×height)	mm	11900×2490×3800
	Full-load Total Weight	kg	28000
