New Type China Sand Wash Production Line For Sale

US$ 6,000 - 10,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, AC Motor

Production Capacity:

98%

Qingzhou Keda Mining Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, AC Motor

Production Capacity 98%

Place of Origin Shandong, China

Brand Name KD

Model Number KDSSJ

Voltage 220V/380V

Power(W) 11kw

Dimension(L*W*H) 2700*1200*1550

Weight 1.5t

Certification ISO9001

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

New Type China Sand Wash Production Line For Sale

1.Introduction of sand wash production line

1)Suitable for use in iron content higher weathering sand, the river sand.

2)This is a complete set of equipment is equipped with chassis, mobile more convenient.

3)The capacity is 30-200 t/h, water can be recycled for saving resources and more environmental protection.

2.Parameter

Basic Parameters of Sand Washer
Type	KDSSJ12-26	KDSSJ15-28	KDSSJ18-30	KDSSJ20-30
Dimension(LWH)	3400x2300x2700	3600x2800x2900	3800x3100x3100	3800x3400x3100
Water wheel dimension	φ2600x1200double row	φ2800x1500double	φ3000x1800triplex	φ3000x2000triplex
Material	8mm	8mm	10mm	10mm
Feeding hopper dimension	3400x1300	3600x1600	3800x1900	3800x2100
Material	4mm	4mm	5mm	5mm
Working capacity m³/h	50-60	80-100	120-150	150-180
Max.approval grain size(mm)	≤12	≤12	≤12	≤12
Main Power(kw)	7.5kw-4	11kw-4	15kw-4	18.5kw-4
Submersible pump
Power	5.5kw	7.5kw	7.5kw	5.5kw x2
Clean Water Flow m³/h	60	65	65	60
Conveyor
Length mm	10000	10000	10000	10000
Belt width mm	600	800	1000	1000
Frame material	12#channel steel	12#channel steel	12#channel steel	14#channel steel
Electromotor kw	5.5	7.5	11	15
