China Supplier Mobile Sand Washing Plant For Sale

FOB Price

USD $6,000 - $10,000 / Set

1 Set(Min.Order)

Product Details

Condition:	New	Type:	Other, AC Motor	Production Capacity:	98%
Place of Origin:	Shandong, China	Brand Name:	KD	Model Number:	KDSSJ
Voltage:	220V/380V	Power(W):	11kw	Dimension(LWH):	Diffrent Model
Weight:	1.5t	Certification:	ISO9001	Warranty:	1 year
After-sales Service Provided:	Engineers available to service machinery overseas

China Supplier Mobile Sand Washing Plant For Sale

1.Introduction of mobile sand washing plant

1)Suitable for use in iron content higher weathering sand, the river sand.

2)This is a complete set of equipment is equipped with chassis, mobile more convenient.

3)The capacity is 30-200 t/h, water can be recycled for saving resources and more environmental protection.

2.Parameter

Basic Parameters of Sand Washer
Type	KDSSJ12-26	KDSSJ15-28	KDSSJ18-30	KDSSJ20-30
Dimension(LWH)	3400x2300x2700	3600x2800x2900	3800x3100x3100	3800x3400x3100
Water wheel dimension	φ2600x1200double row	φ2800x1500double	φ3000x1800triplex	φ3000x2000triplex
Material	8mm	8mm	10mm	10mm
Feeding hopper dimension	3400x1300	3600x1600	3800x1900	3800x2100
Material	4mm	4mm	5mm	5mm
Working capacity m³/h	50-60	80-100	120-150	150-180
Max.approval grain size(mm)	≤12	≤12	≤12	≤12
Main Power(kw)	7.5kw-4	11kw-4	15kw-4	18.5kw-4
Submersible pump
Power	5.5kw	7.5kw	7.5kw	5.5kw x2
Clean Water Flow m³/h	60	65	65	60
Conveyor
Length mm	10000	10000	10000	10000
Belt width mm	600	800	1000	1000
Frame material	12#channel steel	12#channel steel	12#channel steel	14#channel steel
Electromotor kw	5.5	7.5	11	15

3. Mobile sand washing plant

In the work shop

Work site
