Professional Sand Machine And Cleaner

Professional Sand Machine And Cleaner photo-1
US$ 3,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Gravity Separator
Production Capacity:
50-100T/H
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Gravity Separator
Production Capacity 50-100T/H
Place of Origin Shandong, China
Brand Name KEDA
Model Number KDXS
Voltage 220/380V
Power(W) 24-110kw
Dimension(L*W*H) 3400x2300x2700mm
Weight 5t
Certification ISO 9001
Warranty 1year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Professional Sand Machine And Cleaner
1 Durability and no pollution
2 Easy to maintain
3 Manufacturer
4.ISO 9001



Professional Sand Machine And Cleaner





1.sand machine Description:



The products are mainly for the construction of highways, railways, bridges, tunnels high standards of engineering, used to wash aggregated rock of specialized equipment, with ease of movement, processing power, and clean high rate of savings in power and so on, compared with domestic like products.



2.sand machine Application:



Applicable to fine-grained and coarse-grained materials of the washing operation. Stone washing machine in the rational structure, convenient maintenance, handling a large amount of power, consumption is small, clean and high. Novel seal structure, the new shaft installed, adjustable septic tanks to ensure that the product efficiency, durability, cleaning, dewatering effect, and fine-grained features such as product stability.



3.sand machine Feature:



Our sand washing machine has a simple structure, and is easy to maintain.



1)high efficiency and capacity

2)Reasonable structure, high efficiency, and little sand loss during washing;
3)low consumption
4)reasonable structure

5)The most advantageous factor is that the transmission device isolates with sand and water, which greatly reduces the failure rate.



4.sand machine Basic Parameter:

     TypeKDSSJ12-26KDSSJ15-28
Dimension(L*W*H)3400x2300x27003600x2800x2900
Water wheel dimensionφ2600x1200double rowφ2800x1500double
Material8mm8mm
Feeding hopper dimension3400x13003600x1600
Material4mm4mm
Working capacity m³/h50-6080-100
Max.approval grain size(mm)1212
Main Power(kw)7.5kw-411kw-4
Submersible pump
Power5.5kw7.5kw
Clean Water Flow   m³/h6065
Conveyor
Length  mm1000010000
Belt width  mm600800
Frame material12#channel steel12#channel steel
Electromotor   kw5.57.5

5.Our sand machine

Professional Sand Machine And Cleaner Professional Sand Machine And Cleaner

sand machine Working site

Professional Sand Machine And CleanerProfessional Sand Machine And Cleaner

Professional Sand Machine And Cleaner

6.About our company

1)Qingzhou Keda Mining  Machine Co., Ltd. mainly produces iron selecting equipment,kinds of drederes, dredging equipment, sand washing and sand making equipment, gold panning equipment, magnetic separating, crusher and so on, there are more than hundred kinds of products.

2)we design produce various of products according to the customers requirement and geographical condition. It is a modern large-scale mineral processing equipment manufacturer for research and development, engineering design, producing installation, commissioning and after sale service.

3)We have CAD Aided Design R & D center and physical mineral processing laboratory,can work out reasonable and practical solution according to customer's technical requirements and work site,also had established and improve the equipment file and service system, concentrating on customer feedback to make the products constantly improved  to meet the customers' different needs.

Customer vising our company

Professional Sand Machine And Cleaner Professional Sand Machine And Cleaner

Sand machine Delivery before shipping

Professional Sand Machine And Cleaner

Professional Sand Machine And Cleaner

Our service:



1. Pre-sale services:



1)Select proper equipment model;



2)Design and manufacture products according to clients' special requirement;



3)Arrange for visiting our factory, assist them to handle relative procedure, such as visa.



2. Services during the sale:



1) Make sure goods prepared within delivery time;



2)Pre-check and accept products ahead of delivery;



3)Prepare documents required to help customer pass customs clearance.



4)Help clients to make Project evaluation and feasibility analysis and draft solving plans.



3. After-sale services:



1) Assist clients to prepare for the first construction scheme;



2) Install, debug and examine the equipment;



3)Train technical personnel the first-line operators;



4)Provide technical exchanging



5)Offer spare parts at a best price for long term.
