Mining Washing Machine for Sand Washing

Specifications

Mining washing machine for Sand washing

1.Mining washing machine Working Principle

1.The electric motor runs slowly with the impellor after decelerated by the belt, decelerator and gears wheel.

2.The sand and stone flow into washing launder from feeding launder, rolls with the impellor, and grinds each other.

3.The impurity covering the sand is washing away. At the same time, add more water, the strong water flow will take away waste and some low-weight wastes from washing launder. Through the above process, the washing function is finished. The clean sand and stone is lift up by vane. When it goes up slowly, the water begins to drop through the mesh and fall back in the washing launder.

4. water is removed from the sand and stone; on the other hand, the water can be fully used. Finally, the sand and stone goes to the out launder from the rotary impellor to finish the washing task.

2.Mining washing machine  Feature

Our sand washing machine has a simple structure, and is easy to maintain.

1)high efficiency and capacity

2)Reasonable structure, high efficiency, and little sand loss during washing;
3)low consumption
4)reasonable structure

5)The most advantageous factor is that the transmission device isolates with sand and water, which greatly reduces the failure rate.

3.Mining washing machine  Usage and Application

Bucket Sand Washing Machine is a high-efficiency sand washing equipment adopting wheel-like structure, which works with sand making machine. It can wash the stone powder and impurity from the mixed sand that made by sand making machine, which can improve the sand quality. The Sand Washing Machine is widely used in washing, grading and dehydrating in the industry of stone factories, construction site and quartz sand in glass factory.

4.Mining washing machine Basic Parameter:

5.Our Mining washing machine  principle:

1)When it Works, the motor through the V-belt, reducer, gear reducer driven impeller, after the slow rotation, sand and gravel are washed into the tank to the trough, in the impeller, driven by rolling and grinding each other to remove cover the gravel surface impurities, while destruction of the vapor-coated layer of sand to facilitate dehydration;

2)add water to create a strong water flow, in a timely manner a small proportion of impurities and foreign matter away from the export of washing tank overflow discharge to complete the cleaning effect.

3)Clean sand and gravel away from the blade end into the gravel from the rotation of the impeller out of Trough, the completion of gravel cleaning effect.

sand mining washer Working site

6.About our company

1)Qingzhou Keda Mining  Machine Co., Ltd. mainly produces iron selecting equipment,kinds of drederes, dredging equipment, sand washing and sand making equipment, gold panning equipment, magnetic separating, crusher and so on, there are more than hundred kinds of products.

2)we design produce various of products according to the customers requirement and geographical condition. It is a modern large-scale mineral processing equipment manufacturer for research and development, engineering design, producing installation, commissioning and after sale service.

3)We have CAD Aided Design R & D center and physical mineral processing laboratory,can work out reasonable and practical solution according to customer's technical requirements and work site,also had established and improve the equipment file and service system, concentrating on customer feedback to make the products constantly improved  to meet the customers' different needs.

Customer vising our company

Delivery before shipping
