Home > Manufacturing & Processing Machinery > Metallic Processing Machinery > Metal Drawing Machinery > Hose Wire Drawing Machine
Hose Wire Drawing Machine
US$ 30,000 - 80,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Inlet Diameter:
1.5-10mm
Outlet Diameter:
0.05~8.0mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Prestressing Wire Drawing MachineUS$ 30,000 - 60,000MOQ: 1 Set -
Mild Drawing Wire MachineUS$ 30,000 - 60,000MOQ: 1 Set
-
Vertical Wire Drawing MachineUS$ 10,000 - 50,000MOQ: 1 Set
-
High Carbon Wire Drawing Machine LZ8/400US$ 10,000 - 50,000MOQ: 1 Set
-
High Strength Wire Drawing MachineUS$ 20,000 - 50,000MOQ: 1 Set
Condition
New
Inlet Diameter
1.5-10mm
Outlet Diameter
0.05~8.0mm
Place of Origin
Jiangsu, China
Brand Name
wanyi
Model Number
Inverted Vertical
Voltage
380V/220V
Power(W)
7.5~160KW
Dimension(L*W*H)
8420mm*1600mm*1560mm
Weight
1.5~40Ton
Certification
CE/CB//CQC/ISO9001
Warranty
ONE YEAR FREELY
After-sales Service Provided
Engineers available to service machinery overseas
technical parameter for LZ series wire drawing machine
|
Specs (mm) |
No. Of Drafts |
Max. Inlet wire (mm) |
Min. Outlet wire (mm) |
Motor Power (KW) |
Max. Speed (m/s) |
Noise dB(A) |
Φ250 |
9-12 |
1.8 |
0.35 |
2.2-4 |
12 |
80-82 |
Φ350 |
6-12 |
3.5 |
0.6 |
7.5-11 |
20 |
80-82 |
Φ400 |
6-12 |
4.2 |
0.75 |
11-15 |
20 |
80-82 |
Φ450 |
6-12 |
4.6 |
0.85 |
15-22 |
18 |
80-82 |
Φ500 |
6-12 |
5.5 |
1.0 |
22-37 |
18 |
80-82 |
Φ560 |
6-12 |
6.5 |
1.3 |
22-45 |
18 |
80-82 |
Φ600 |
5-10 |
7.0 |
1.8 |
37-55 |
16 |
80-82 |
Φ700 |
4-9 |
8.0 |
2.4 |
45-75 |
12 |
80-82 |
Φ800 |
4-9 |
10 |
2.8 |
55-90 |
10 |
80-82 |
Φ900 |
4-9 |
14 |
3.5 |
75-132 |
8 |
80-82 |
