High Strength Wire Drawing Machine

High Strength Wire Drawing Machine thumbnail-1
High Strength Wire Drawing Machine thumbnail-2
High Strength Wire Drawing Machine thumbnail-3
High Strength Wire Drawing Machine thumbnail-4
High Strength Wire Drawing Machine thumbnail-5
High Strength Wire Drawing Machine thumbnail-6
High Strength Wire Drawing Machine photo-1
High Strength Wire Drawing Machine photo-2
High Strength Wire Drawing Machine photo-3
High Strength Wire Drawing Machine photo-4
High Strength Wire Drawing Machine photo-5
High Strength Wire Drawing Machine photo-6
US$ 20,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
Zhangjiagang City Wanyi Machine Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or your needs
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
CNC or Not Normal
Place of Origin Jiangsu, China
Brand Name Wanyi
Model Number LZ600
Voltage 380V
Power(W) 7.5-90KW
Dimension(L*W*H) 8500X1600X1450MM
Weight 7000kg
Certification CE or SGS or other third parts
Warranty one year freely
After-sales Service Provided Engineers available to service machinery overseas

high strength wire drawing machinehigh strength wire drawing machinehigh strength wire drawing machinehigh strength wire drawing machinehigh strength wire drawing machine

high strength wire drawing machinehigh strength wire drawing machineSpecifications

1.ISO 9001:2008 standard certification
2.main foreign markets: mid-east,southeast Asia,south Asia,Africa,etc.

Detailed Sell  Lead  Description:

Description:               LZ600 High speed straight wire drawing machine

Place Of Origin:          Zhangjiagang City, Jiangsu, China

Company Published:   2009

Business type:          Manufacturer

Number Of Employees:     50-100

Package:              wooden case..

Feature:             Applicable for drawing high, medium, low carbon steel wire/ alloy steel wire/ stainless steel wire,

with the feature of continuous pass drawing. The machine is controlled by PLC which is driven by frequency converter.



Specification:

Item

LZ200

LZ300

LZ400

LZ500

LZ560

LZ600

LZ700

LZ750

LZ900

LZ1200

Dia. of Capstan

200mm

300mm

400mm

500mm

560mm

600mm

700mm

750mm

900mm

1200mm

Capstan Nos.

2~12

2~12

2~12

2~12

2~12

2~9

2~9

2~9

2~9

2~9

Inlet wire size

2.5mm

2.8mm

4.2mm

5.5mm

6.5mm

8mm

10mm

10mm

14mm

16mm

Finished wire

0.3mm

0.6mm

0.7mm

1.2mm

1.3mm

1.6mm

2.2mm

2.2mm

3mm

3mm

Max. Speed

20m/s

20m/s

20m/s

18m/s

15m/s

12m/s

10m/s

10m/s

8m/s

6m/s

Power (Kw)

5.5~7

7.5~11

7.5~22

22~45

22~55

45~75

45~90

55~90

90~132

90~160
