sand making production line 30-500t/h :
1.ISO9001:2000
2.Price:negotiable
3.Capacity:5-800T/H
4.Payment terms:L/C or T/T
sand making production line application:
Our sand production line mainly consists of vibrating feeder, jaw crusher, sand making machine, vibrating screen, sand washing machine, belt conveyor, electric control panel, etc, and capacity is 30-500T/H. Sand making production line is mainly composed of vibrating feeder, jaw crusher, fine jaw crusher ( or counterattack crusher ), vertical shaft impact crusher ( sand making machine ), vibrating screen, sand washing machine, centralized electric control and belt conveyor.
sand making production line brife introduction:
Large stone is transported to jaw crusher via vibrating feeder for primary crushing. Then crushed material is transported to sand making machine. Then the stones are screened out into several different types with a vibrating screen. Stone with satisfied size is transported to sand washing machine, then it will be final product, while overlarge stone is returned back to sand making machine for recrushing.
sand making production line process:
The raw material is transferred to jaw crusher for primary crushing by vibrating feeder, then the crushed materials are transferred to sand-making machine through belt conveyor for secondary crushing. The materials crushed will be transferred to the vibrating screen. The materials with suitable size will be transferred to sand washing machine, after being washed, then clean final products will be discharged. The others with unsuitable size will be screened from vibrating screen, then will be transferred to the sand-making machine, this forms a closed circuit manifold cycles.
Sizes of final products will be according to our customers' requirements. If it is the dry process, the classifier and deduster will be attached according to you requirement.
Characteristics of sand making production line :
It is highly automatic. The efficiency is high, operation cost is low, crushing ratio is high, capacity is high, and pollution is very low. Size of final product is even, and with good shape, which complies with requirement for highway.
In order to minimum occupation area, we try to make full use of space. Advanced electric control system makes the full line very smooth, reliable, and easy to maintenance.
sand making production line main technical parameters:
Model | XSD2212 | XSD2612 | XSD2812 | XSD3015 | XSD3215 | XSD3615 |
Impeller diameter (mm) | Φ2200 | Φ2600 | Φ2800 | Φ3000 | Φ3200 | Φ3600 |
Impeller rotating speed (r/min) | 1-1.5 | 1-1.5 | 1-1.5 | 1-1.5 | 1-1.5 | 1-1.5 |
Capacity (t/h) | 15-35 | 20-50 | 30-65 | 50-80 | 80-120 | 120-180 |
Feed size (mm) | ≤10 | ≤10 | ≤10 | ≤10 | ≤10 | ≤10 |
Weight (t) | 2 | 2.68 | 3 | 3.4 | 3.9 | 4.5 |
Power (KW) | 5.5 | 5.5 | 7.5 | 11 | 11 | 15 |
