Rotary sifter for gold ore washing plant :
Rotary sifter introduction:
Rotary drum screen is used to separate materials by size, for example, separating the biodegradable fraction of mixed municipal waste or separating different sizes of mulch or crushed stone or sawdust, whose production capacity is 3t/h.
Rotary sifter advantages:
Drum screen is a classification machine for various kinds of materials such as coal, river sand, ore, refractory materials, gravel, chemical, waste etc. It has the excellent features including low noise, good sealed, high efficiency, large capacity of classfication, long service life time and so on.
Rotary sifter main technical parameters:
Model |
Specification (m) |
Slope |
Rotary speed |
Sieve pore(mm) |
Max feeding size (mm) |
Production capacity(m3/h) |
Motor power (kw) |
|
Sieve pore(2mm) |
Sieve pore(20mm) |
|||||||
GTS820 |
Φ0.8X2 |
6° |
32 |
2-20 |
Mesh size X2.5 |
7 |
30 |
3 |
GTS830 |
Φ0.8X3 |
6° |
32 |
2-20 |
Mesh size X2.5 |
8 |
50 |
3 |
GTS1030 |
Φ1X3 |
6° |
25 |
2-20 |
Mesh size X2.5 |
10 |
60 |
4 |
GTS1040 |
Φ1X4 |
6° |
25 |
2-20 |
Mesh size X2.5 |
11 |
80 |
4 |
GTS1230 |
Φ1.2X3 |
6° |
20 |
2-20 |
Mesh size X2.5 |
12 |
100 |
5.5 |
GTS1240 |
Φ1.2X4 |
6° |
20 |
2-20 |
Mesh size X2.5 |
14 |
120 |
5.5 |
GTS1250 |
Φ1.2X5 |
6° |
20 |
2-20 |
Mesh size X2.5 |
15 |
140 |
5.5 |
GTS1530 |
Φ1.5X3 |
6° |
17 |
2-20 |
Mesh size X2.5 |
16 |
120 |
5.5 |
GTS1540 |
Φ1.5X4 |
6° |
17 |
2-20 |
Mesh size X2.5 |
18 |
150 |
7.5 |
GTS1550 |
Φ1.5X5 |
6° |
17 |
2-20 |
Mesh size X2.5 |
20 |
180 |
11 |
GTS1560 |
Φ1.5X5 |
6° |
17 |
2-20 |
Mesh size X2.5 |
22 |
200 |
11 |
1.Installation: The seller provide all drawings for installation, engineers available to service machinery overseas.
2.After sale service: 1year guarantee.
