Nonmetal Small Batch Ball Mill/Ceramic Ball Mill For Feldspar,Quartz :
Batch ball mill, also known as a one-time feed mill, is one of the mill products of our company and mainly used for material mixing, grinding. The finished product is characterized by uniform fineness and power savings. Either dry grinding or wet grinding is available. The aircraft can use the steel liner plate or silica liner, to meet different needs. Motor auto decompression start to reduce the starting current, and its structure can be divided into the overall style and detached. This product has less investment than similar products, energy saving, the novel structure, easy operation, use of safe, stable and reliable performance characteristics, suitable for general and special material mixing and grinding operations.the liner material can be Ceramics, silica, rubber and metal (the liner material and grinding materials determine the power)
Contact: Ms Nancy
Mobile phone(whatsapp): 0086 13613714234
Skype: gaoyan906820
Batch ball mill /small batch ball mill with ceramic liner working principle:
During dressing production, only a very small number of ore after crushing, screening can be directly sent to smelting, while most of the ore has to finely ground to 0.1-0.074mm even finer, so that the useful minerals to achieve monomer dissociation, and after sorting can be sent to the election smelting. Therefor grinding job is very important in the dressing production process. If don't have mineral monomer dissociation , then would not electe good grade of powder. In our dressing production, the mill common used for grinding operations, is ball mill, rod mill, and autogenus tumbling mill. In addition , extensive use of various types of mill in building materials, chemicals, electricity, ceramics and other industrial sectors, such as tube mills used in cement plant for finely ground raw materials and clinker, Ball Mill is used in thermal power plants for pulverizing coal to act as fuel of boiler.
Batch ball mill main technical parameters:
| Model | Charge Amount(t) | Cylinder Speed(r/min) | Power(kw) | Lining Plate Quality |
| 600 * 700 | 0.05 | 50 | 2.2 | Wear resistant corundum lining brick,silica,rubber, metal(matched power is different according to lining plate quality and grinding materials.) |
| 800 * 600 | 0.075 | 42 | 3 | |
| 900 * 1200 | 0.2 | 38.5 | 5.5 | |
| 1300 * 1500 | 0.5 | 33 | 7.5 | |
| 1500 * 1800 | 1.2 | 28.5 | 11 | |
| 1800 * 2000 | 1.5 | 24 | 15 | |
| 2600 * 2800 | 5 | 16.5 | 37 | |
| 3000 * 3800 | 10 | 14.5 | 57.2 | |
| 3200 * 4600 | 15 | 13.5 | 75 | |
| 3400 * 6600 | 18 | 13 | 135 |
