Fertilizer rotary dryer application:
Fertilizer rotary dryer is mainly used to drying the humidity and granules of fertilizer in manufacture of compound fertilizers. Meanwhile, it also can widely apply to drying many other various materials.
The consit of fertilizer rotary dryer :
the dryer is formed by rotary body, lifting blade, driving device, supporting device and sealing ring.
Fertilizer rotary dryer working principle:
The raw material plate is arranged conveniently to allow adjustable angle positions. The material to be dried is inserted to the rotary cylinder through the raw material plate. Hot air flows within the cylinder causing the separation of water from the material by converting it into vapor which is discharged into the atmosphere. At this point, the material becomes dry.
Fertilizer rotary dryer characteristics :
(1). The internal adopts assembled structure which has improved the accuracy of the equipment and it is easy to transport and install.
(2). According to the characteristics of different fertilizers ,we have arranged the second granulation zone reasonably so as to improve the granulation effect .
(3). Adopts assembled hoist board so as to exchange heat fully and lower the energy consumption .
(4). Temperature induction monitor ,uniform vibration and airproof setting , which improve performance and productivity efficiently .
(5). The assorted combustion furnace is a type of energy efficient and has the characteristics of smaller area , easy regulation and equipped with greenhouse
Fertilizer rotary dryer main technical parameters:
Fertilizer rotary dryer main technical parameters:
Type |
Gradient(%) |
Speed(r/min) |
Inlet air temperature |
Power(KW) |
Production(t/h) |
Weight(t) |
600*6000 |
3-5 |
3-8 |
≤ 700 |
3 |
0.5-1.5 |
2.9 |
800*8000 |
3-5 |
3-8 |
≤700 |
4 |
0.8-2 |
3.5 |
800*10000 |
3-5 |
3-8 |
≤700 |
4 |
0.8-2.5 |
4.5 |
1000*10000 |
3-5 |
3-8 |
≤700 |
5.5 |
1-3.5 |
5.6 |
1200*10000 |
3-5 |
3-8 |
≤700 |
7.5 |
1.8-5 |
14.5 |
1200*12000 |
3-5 |
3-8 |
≤700 |
11 |
2-6 |
14.8 |
1500*12000 |
3-5 |
2-6 |
≤700 |
15 |
3.5-9 |
17.8 |
1800*12000 |
3-5 |
2-6 |
≤700 |
18 |
5-12 |
25 |
2200*12000 |
3-5 |
15-6 |
≤700 |
18.5 |
6-15 |
33 |
2200*18000 |
3-5 |
15-6 |
≤700 |
22 |
10-18 |
53.8 |
2200*20000 |
3-5 |
15-6 |
≤ 700 |
30 |
12-20 |
56 |
2400*20000 |
3-5 |
15-5 |
≤700 |
37 |
18-30 |
60 |
3000*20000 |
3-5 |
15-5 |
≤ 700 |
55 |
25-35 |
78 |
3000*25000 |
3-5 |
15-5 |
≤700 |
75 |
32-40 |
104.9 |
