Breakfast cereals use grain as the basic raw material. By the processing line it is processed to flakes instant food which is pressed by particle. The outstanding feature is that it is rich in composite carbon compounds and dietary fiber. At the same time,cereals can not only strengthen much trace element, such as vitamins and minerals, but also add cocoa and sugar, such as honey,maltose, etc. After adding into coffee,milk,yogurt,or functional drinks, we can directly eat it. Children can also eat it as sweet and brittle leisure snack food.
1. Raw Materials: Corn Powder and Other Cereals
2. Products: All kinds of snacks with different shapes and types.
3. Capacity: 120-150 KG/H,200 KG/H,300-400 KG/H
4. Flow Chart: Mixing —Extruding —Flaking —Drying — Baking —Coating —Baking —Cooling
5. Voltage: Three phases: 380V/50HZ, Single phase: 220V/50HZ, we can make it according to customers' local voltage of different countries
6. Machines Materials: All the machines are made by food grade stainless steel.
7. Technical Parameters
Mixer Function and Features:
Mixer makes the raw material which adding water and liquid chemical additive fully mixed equally. the machine mixes the flour and prepares them ready to be used in the next step.
1. Surface which touches mixer and raw material adopt stainless steel;the mixer is easy to operate it.
2.The discharge hole adopts the new handle-opened design, good seal and avoids leaking the material
3. we can choose different install powder mixer to meet the extruder capacity require.
Double screw food extruder Features:
1. Alloy (38CrMoAL) screw made by nitriding process, high strength and wear-resting. Self-cleaning ability, no need to discharge or clean the barrel and screw when roasting or replacing of materials.
2. Adopting speed-adjusted converter on feeding system, extrusion system and cutting system. Food grade stainless steel twin screw feeding machine, stable materials feeding in the whole food process.
3. Gearbox with automatic lubrication function, extending gear life.
Name: Cooling Conveyor
Brand: Datong
Original: China
It is full set stainless steel.The height of the hoister can be adjusted based on the requirement.
Machine Parts: dryer
2.The belt and the heat preservation use the stainless steel; it is suitable for food safe industry level.
3.The running speed of belt net can be controlled (frequency controlling system)
4.The temperature can be controlled willfully and designed according to the need.
5. Adjustable transit speed of net belt with accurate temperature control device.
6. Suitable to dry non-fried extrusion snacks, nutritional powder, bread crumb, pet food, soybean protein, etc.
Screw Parameter:
Nitriding treatment(120 Hours)
Depth of Nitrided Layer: 0.5-0.8 mm
Hardness of Nitrided Layer: 950-1100Hv (HRC56°-65°)
Chrome Plating
Thickness of Hard Chrome Plating Layer: 0.05-0.10mm
Wear sleeve and screw sleeve are made of high wear-resistant alloy steel, to reduce abrasion and prolong service life.
Name: Air conveyor
Brand: Datong
Original: China
Air conveyor is used to convey the produces to the dryer.It is suitable for long distance conveying.It has features of low consumption and high efficiency without leaking and pollution .
1.Manufacture:
1)Keep the quality the first.
2)Make more products benifit to customers' need. _______________________________________________________________________
2.Online/Sale service:
1)Supper and solid quality.
2)Fast and punctyal delivery
3)Standard export package or as customers' need.
________________________________________________________________________
3.After-sale service:
1)Assistance to build factory or your project.
2)Repairing and maintenance if any problem occur in the warranty.
3)Installation and clerks training.
4)Spare and wearing parts for free or with big discount.
5)Any feed back of machines can be told us, and we will try our best to support you. ________________________________________________________________________
4.Other cooperate service:
1)Technology knowledge share.
2)Factory building advising.
3)Business expansion adbvising.
1. Are You a manufacturer or a trading company?
We are professional manufacturer of food making machine
2. Where is your factory located?
Our factory is located in Jinan city,Daqiao Haojing industrial park,Tianqiao Zoon,Shangdong Province,China
3. What’s your price of your food making machine?
Please contact us by send inquiry to us directly ,We will reply you as soon as possiable
4. How to support me,if I don’t know how to use it?
Free training within the warranty period will be provided by telephone or email or skype.We also can let our technican to customer’s company to provided training and support
5. If machines’ wearing parts need changing ,what should we do?
We can offer wearing parts all the time ,and offer video to show how to change it.
6. What’s the payment term,if we want to buy machines ?
L/C,100%T/T,Alibaba Trade Assurance,T/T30% down payment ,70%balance delivery.
