High Profile Mobile Stone Crusher From China

Name: High Profile Mobile Stone Crusher From China
Brand: Yuhui
SKU: 141245576
Availability: InStock

US$ 10,000 - 999,999 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Jaw Crusher

Application:

crushing

Henan Yuhui Mining Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Dalian Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Jaw Crusher

Application crushing

Motor Type AC Motor

Power(W) different model

Capacity(t/h) 200-500t/h

Place of Origin Henan, China

Brand Name Yuhui

Model Number many types

Dimension(L*W*H) different model

Weight different model

Certification ISO, BV

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

Specifications

high profile mobile stone crusher from china
1.within 30 days delivery
2.ISO9001:2000. CE
3. higher carrying capacity

high profile mobile stone crusher from china

mobile stone crusher verview:

mobile stone crusher comes in all shapes and sizes and can be made up of many different kinds of equipment. When it comes to portable and moblie crushing plant, Recycling attachments, aggregate plant and industry grinding mill plant, count on us as your single source supplier for equipment.
YUHUI has been serving the aggregate industry for over 30 years, it is one of the most famous rock and mineral processing company in the world, the portable crushing plant concept designed by us is fully adaptable to all mobile crushing needs.

excellent performance of mobile stone crusher:

mobile stone crusher application:

The portable plant term for sand, gravel and stone, which can be used to make concrete amongst other things. They can be compacted to firmly fill a space and are often bound together with cement, to make concrete or bitumen, to re-surface roads.

This crushing plants incorporate all the crushing plants into one which eliminate the work to install the basic facilities in the bumpy ground when you use the independence crushing plants, reduce the cost of the material and man-hour. This reasonable and compact arrangement of the equipments improves the flexibility to set-up these machines.

specification of mobile stone crusher:

Model Parameters	YG938E69	YG1142E710	YG134E912	YG134J811
Transport Length (mm)	11900	13100	14600	14600
Transport width (mm)	2550	2550	2950	2550
Transport height (mm)	3650	4450	4500	4500
Maximum length (mm)	12100	13300	14600	14600
Maximum width (mm)	2900	2950	3300	3300
Maximum height (mm)	4060	4810	5300	5300
Weight (T)	39	57	83	65
Tire configuration and installation	dual-axis C	three-axis C	four-axis C	four-axis C
Crusher Type	PE600×900	PE750×1060	PE900×1200	JC840×1100
Max feed (mm)	480	630	750	720
Discharge port adjustment range (mm)	65~160	80~140	95~165	100~225
