Specifications
Mobile Jaw Crushing Plant1.CE&ISO certificate
2.capacity10-240m3/h
3.negotiable price
4.applied in construction,metallurgy
Mobile Jaw Crushing Plant
Jaw Crushing Plant Application:
Mobile crushing plant is a kind of crushing machine mainly used for processing materials in smelting, chemical industry, production of building materials, and power industry, etc. It is especially suitable for processing the stones used in road building and hydraulic power projects. Users can adopt different configurations according to categories and sizes of materials, and so on.
Jaw Crushing Plant Specialties:
1.Integrated machine set
Integrated machine set is easy to install. This can not only eliminate complicated installation work, but also lower the consumption of materials and working hours. The rational and compact structure makes the tire mobile crushing machine easy to be stationed.
2. Flexible maneuverability
The tire mobile crushing station has the characteristics of high chassis, narrow body, and small turning radius, which makes it easier to run on the highway, even on uneven ground surfaces in crushing sites, thus saving time and money. Mobile crushing station can provide more flexible space and reasonable layout configuration for the whole crushing process.
3. Low transportation cost
Tire mobile crushing station can crush the materials on-site, so there is no need to transport the materials to a certain site for crushing. This largely reduces the transportation cost.
In addition, the lengthened machine can send the crushed materials directly into the transport truck.
Main Technical Parameters
PP jaw portable crusher | PP600 | PP750 | PP900 | PP1060 | PP1200 | PP1300 | |
Shipping size | Length(mm) | 8600 | 9600 | 11097 | 13300 | 15800 | 9460 |
Width(mm) | 2520 | 2520 | 3759 | 2900 | 2900 | 2743 | |
Height(mm) | 3770 | 3500 | 3500 | 4440 | 4500 | 3988 | |
Weight((kg) | 15240 | 22000 | 32270 | 57880 | 98000 | 25220 | |
| Axle load(kg) | 10121 | 14500 | 21380 | 38430 | 64000 | 14730 |
Tractor weight(kg) | 5119 | 7500 | 10890 | 19450 | 34000 | 10490 | |
Jaw crusher | Type | PE400X600 | PE500X750 | PE600X900 | PE750X1060 | PE900X1200 | PE300X1300 |
Material inlet(mm) | 400X600 | 500X750 | 600X900 | 750X1060 | 900X1200 | 300X1300 | |
Adjusting range of discharge hole(mm) | 40-100 | 50-100 | 65-180 | 80-180 | 95-225 | 20-90 | |
Capacity(m3/h) | 10-35 | 25-60 | 30-85 | 70-150 | 100-240 | 10-65 | |
Vibrating feeder | Type | GZD8030 | GZD8030 | GZD9638 | GZD1149 | GZD1325 | GZD8030 |
Capacity of material cabin(m3) | 3 | 4 | 7 | 10 | 10 | 3 | |
Width of material cabin(mm) | 2200 | 2500 | 3000 | 3000 | 3000 | 2200 | |
Belt conveyor type | B500X6 | B650X7 | B800X8 | B1000X11 | B1200X13 | B800X7 | |
