Specifications
MTM raymond mill manufactured by china yuhui hot1.adopts Germany technology
2.over 30 years experience
3.quality is first
MTM raymond mill manufactured by china yuhui hot
1. Constructure:
MTM RAYMOND MILL consists of motor, reducer, case, milling device, separator, outlet, coal feeding pipe, loading device, control box and sealing apparatus. The fittings are all of superior performance in the world at present. We ensure good quality and durability of the whole machine.
2. Special Features :
1) The concrete base weight required is only 3 times of that of other similar machines thus the construction expenses is greatly reduced ;
2) Small vibration while using and doesn't need shock-absorbing device;
3) Large load adjustment scope, so it can run under various environments;
4) Can bear very strong explosion pressure;
5) The grinding roller adopts new material and new craft, which ensures long service life and low maintenance cost;
6) There is gap between the grinding parts; it can start with load or offload.
3.Application:
MTM RAYMOND Mill is applicable to the grinding and processing of more than 280 kinds of non-flammable and non-explosive materials with hardness less than 7 and humidity less than 6% in mining, construction, chemical industry and metallurgy, such as barite, calcite, feldspar, talcum, marble, limestone, clay, glass. The fineness of the finished product can be adjusted from 100 mesh to 325 mesh according to requirements.
4.Technical parameters:
Item | MTM100 | MTM130 | MTM160 |
Number of roller | 4 | 5 | 6 |
Major diameter of roller ×Height(mm) | Φ320×200 | Φ410×240 | Φ440×270 |
Internal diameter of roller × Height(mm) | Φ980×200 | Φ1280×240 | Φ1600×270 |
Main engine spindle speed(mm) | 130 | 103 | 82 |
Maximum feeding grain size (mm) | <25 | <30 | <35 |
Grain size of finished product (mm) | 1.6 -0.038 | 1.6 -0.038 | 1.6 -0.038 |
Output (t/h) | 3 - 8.8 | 6 -13 | 13 -22 |
Overall dimension (mm) | 9910×5365×8310 | 7910×7000×9645 | 12550×5700×8355 |
Weight(t) | 16 | 26.1 | 35 |
Note: This specification is just reference, any changes are subject to the Raymond mill products.
Our company established in the 1970s , Henan Yuhui Mining Machinery Co., Ltd has developed into a manufacturer,specialized in producing mineral dressing equipment , sand making equipment, cement equipment, compound fertilizer equipment .
