Specifications
2012 new high quality raymond mill1.Simple structure
2.Easy oeration
3.price:negotiable
4.ISO9001:2000
2012 new high quality raymond mill sell to Pakistan
A. Working principle:
In the micro-power grinding room,the rollers hanged on the roller lifting frame,which is fixed with the main sheft and the scraper knife.the pressure spring press on the outer of the cantilever by tension rod,with the corss arm sheft as the supporting point.let roller tightly press on the inner surface of the ring.when the motor moved with equipment,the scraper knife on the scraper frame moved with the roller at the same time.as the roller moved on the inner sphere surface and moved itself.analyzer let the analyzer runner rotated by motor equipments,and the power fineness depend on the speed adjustment of the analyzer.
B. Features:
1) The grinding roller adopts new material and new craft, which ensures long service life and low maintenance cost;
2) There is gap between the grinding parts; it can start with load or offload.
3) High capacity and low cost
4) Professional after-sales service
C. Application:
Raymond mill is suitable in grinding bartle,limestone,ceromic,coking coaland so on.it is mainly applied to the power processing of mineral products in the industries of mining,metallurgy,constrution materials and chemical materials.ect.more than 280 kinds of high finesse power grinded.
D. Main technical parameters:
Model | Rollers NO | Rollers size | Ring size | Max feed size | Finished size | Processing capacity(t/h) | Mainframe power | Overall dimension | ||
(pcs) | (mm) | (mm) | (mm) | (mm) | 0.125 | 0.075 | 0.044 | kw) | (LxWxH) | |
GDM-260 | 3 | Ø260x150 | Ø780x150 | 15 | 0.613-0.033 | 2.2-3.0 | 1.5-2.2 | 1.0-1.4 | 18.5 | 4300X3500X5100 |
GDM-280 | 3 | Ø270x140 | Ø830x140 | 20 | 0.613-0.033 | 3.4-4.6 | 2.2-2.8 | 1.2-2.0 | 22 | 5300X4100X5200 |
GDM-310 | 4 | Ø310x170 | Ø950x170 | 25 | 0.613-0.033 | 4.3-5.6 | 3.0-3.8 | 2.1-3.5 | 30-37 | 7100X5900X7900 |
GDM-320 | 4 | Ø320x160 | Ø970x160 | 25 | 0.613-0.033 | 4.5-6.0 | 3.1-4.0 | 2.0-3.6 | 37 | 9900X5800X7500 |
GDM-410 | 5 | Ø410x210 | Ø1280x210 | 30 | 0.613-0.033 | 5.0-10.5 | 4.0-6.6 | 2.8-5.4 | 75 | 9200X7300X9700 |
GTM-320 | 4 | Ø320x200 | Ø980x200 | 25 | 1.6-0.045 | 3-8.8 | 45 | 7300X5365X8310 | ||
Note: This specification is just reference, any changes are subject to the Raymond mill products.
