Home > Products > Auxiliary equipment for beneficiation > YuHui brand wet gold mill for selecting gold
YuHui brand wet gold mill for selecting gold
- 100 Set / Sets per Month
- Tianjin ingdao Shanghai
- T/T
Product Details
Condition: | New | Type: | Other | Motor Type: | AC Motor |
Power(W): | 5.5-37kw | Place of Origin: | Henan, China | Brand Name: | Yuhui |
Model Number: | many types | Dimension(L*W*H): | according to different types | Weight: | according to different types |
Certification: | ISO9001:2000 | Warranty: | 1year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
wet gold mill
1.wet Grinding Machine Application and Function:
Our grinding machine is mainly used for separation of gold, silver, lead, zinc, molybdenum, iron, copper, antimony, tungsten, tin and other minerals selected. With less investment, fast results, small footprint, saving power, sturdiness and durability, ease of maintenance and high return on investment. It is the preferred production for alternative ball mill, is ideal for small and medium enterprises dressing.
2.wet Grinding Machine Specification:
Wet grinding machine is made of restructuring on the basis of conventional machine, For the traditional machines, the workpiece is large and short lifetime, electrical power large, installation cycle is long, the user can not immediately put into production, maintenance and replacement of materials need for large lifting equipment .
3.wet Grinding Machine main technical parameters:
Model | Specification(mm) | Feeding size | Speed(r/min) | Power(kw) | Weight(t) |
1600A | 1600*500*200*500+20 | Feeding size less than 3cm | 20-22 | 37 | 14.5 |
1500A | 1500*350*200*460+20 | 20-22 | 22 | 13.3 | |
1500B | 1500*350*150*460+20 | 20-22 | 22 | 12.3 | |
1500C | 1500*300*150*420+20 | 20-22 | 18.5 | 11.3 | |
1400A | 1400*250*150*350+20 | 16-18 | 18.5 | 8.5 | |
1400B | 1400*250*150*350+20 | 21-23 | 18.5 | 8.5 | |
1350A | 1350*250*150*350+20 | 16-18 | 18.5 | 8 | |
1350B | 1350*250*150*350+20 | 21-23 | 18.5 | 8 | |
1300A | 1300*250*150*350+20 | 16-18 | 15 | 7.5 | |
1300B | 1300*250*150*350+20 | 21-23 | 15 | 7.5 | |
1200A | 1200*220*80*270+20 | 17-19 | 7.5 | 5.5 | |
1200B | 1200*200*80*250+20 | 23-25 | 7.5 | 5.5 | |
1100A | 1100*200*80*250+20 | 17-19 | 7.5 | 5 | |
1100B | 1100*200*80*250+20 | 23-25 | 7.5 | 5 | |
1000 | 1000*200*80*250+20 | 13-15 | 5.5 | 4.5 |
Contact Us
- Henan Yuhui Mining Machinery Co., Ltd.
- Contact nameLizzy zhang
- Phone086-0371-55611752
- AddressWest 4th ring road and huagong road crossroads.1000 meters westward. Zhengzhou,Henan
