gold ore concentrated machine

Specifications

gold ore concentrated machine
1. ISO9001:2000, CE
2. 30 years experience
3. more efficient
4. welcome



gold ore concentrated machine



1. concentrate machine application:



The High efficiency concentrator machine of our company is suitable for dehydrating water of the concentration and gangue in the concentrating factory which can make the mash of 20-30% raise up to 40-70% about. It is widely used for melting, chemical, coal, non metal concentration, environment protected etc industry.



2. concentrate machine features:



(1) Adding flocculating agent, bigger the diameter of the deposit solid grain, speed up the deposit.
(2) Set the lean board, reduce the mash deposit distance, increase the deposit square.
(3) Have effect on flocculating. Percolating, compressing and dealing quantity of the slurry deposits.



3. concentrate machine main technical parameter:



Model and  specification	Concentration tank		Revolution of target frame (r/min)	Drive motor			Production capacity   (t/d)
	Diameter  (m)	Depth (m)		Model	Power (KW)	Rotational speed (r/min)
TNZ-1.8	1.8	1.8	0.5	Y90L-6	1.1	910	1.3-5.6
TNZ-3.6	3.6	1.8	0.4	Y90L-6	1.1	910	5-24
TNZ-6	6	3	0.3	Y90L-6	1.1	1430	14-62
TNZ-9	9	3	0.26	Y90S-4	3	960	32-150
TNZ-12	12	3.5	0.19	Y132S-6	3	960	250
TNZ-15	15	3.6	0.113	Y132M2-6	5.5	940	390
7metres ,3stores	7	7	0.2481	Y112M-6	2.2	94O	15-50
7metres,4stores	7	9. 5	0.481	Y112M-6	2.2	940	15-50
9metres.3stores	9	6. 8	0.8	Y132M2-6	5.5	960	≤88
12metres.4stores	12	7.23	0.2	Y132M2-6	5.5	960	≤160
15metres,3stores	15	7.8	0.15	Y160M2-8	5.5	720	≤250

....
