Specifications
physical beneficiation machine:1.recoil water yield-2.7-4.1m2/h
2.easy operation
3.environment friendly
4.capacity1.5t/h.
alluvial gold concentrate machine from gulch-gold,gold vein,metal minerals
General Introduction
Our company's gold physical beneficiation machine is mainly applied in gold dust, vein gold ore and the monomer gold recovery of polymetallic ore, but also separate monomer gold from the gold-bearing flotation concentrates and old tailings.
Working Principle
Gold physical beneficiation process is a purely physical gold process to separate gold based on the proportion difference of gold element and other elements and different trajectories under the action of the gravity gradient field and centrifugal force in the beneficiation machine, so sulfur, arsenic and other harmful elements in the ore does not affect the gold physical beneficiation process.
Advantages and Features
As its easy use and less auxiliary equipment of YuHui brand LX physical gold beneficiation machine and gold beneficiation concentrating table, therefore it needs small plant size and a small investment in building the plant. Because there is no pollution, so plant site selection is more flexible, the machine appears more advantages particularly in the area environmental protection requirements is more stringent.
YuHui brand LX gold physical beneficiation machine can reach more than 95% recovery rate to particle size larger than 50 microns monomer gold and can dress the monomer gold as small as 10 micron particle size. If you have crusher, ball mill, you can add after the original equipment our physical gold beneficiation machine to directly upgrading to pollution-free physical gold beneficiation device.
Technical Parameters
Model | LX-25 |
Capacity(t/h) | 1-1.5 |
Motor power(kw) | 1.1 |
Feeding size(mm) | ≤3 |
Feeding density | 0-75% |
Standard feeding density | 35% |
Concentrate output (kg) | 3-5 |
Discharge ore cycle (h) | 1-4 |
Recoil water yield(m3/h) | 2.7-4.1 |
Recoil water pressure(Mpa) | 0.03-0.06 |
Note: The technical parameters above are just for your reference. If there is any change, all parameters and overall dimension are subject to operating instructions. Any questions please feel free to contact us.
