S314 Desktop 4-Axis Soldering Robot
Apollo Seiko heating controller system and technology
Suitable for smaller solder joints
Fast heating up
| Soldering Robot | S514 Desktop 4-Axis Soldering Robot |
| Voltage | 110V/220V AC |
| Heating Power | 300W |
| Preheating Temperature Range | 300℃-500℃ |
| Axis | 4 Axis |
| Operating Range | 400mm x 400mm x 100mm (X*Y*Z) |
| Repeatability Accuracy | ±0.02mm (X*Y*Z) |
| Min. Analysis | 0.01mm (X*Y*Z) |
| Solder Wire Diameter | 0.5,0.6,0.8,1.0,1.2 (mm) |
| External Dimensions | 720 x 700 x 810mm |
| Weight | about 66 kgs |
Description:
1. The multi-axis linkage robot, with the drive of precise stepper motor and the advanced motion control algorithm, effectively
improves the positioning accuracy and repeat precision.
2. With the embedded industrial computer control, the robot can achieve different tasks such as single joint / single time / cyclic
soldering operation.
3. With the handheld LCD Teaching Pendant, the programming is simple and easy to learn. You can enter directly the
coordinates of the solder joint, or you can teach and playback the position coordinates. As the teaching programming is quite
simple, even beginners can quickly grasp the operation essentials.
4. The soldering iron unit can be adjusted to any angle or any direction. It can achieve 360℃ free rotation by controlling the R-axis.
According to different solder pad and components, you can set at will the solder feeding times, preheating time and soldering time,
to achieve the complicated soldering work.
5. With an external I/O interface, it can fulfill the functions such as real-time control on peripheral devices, intelligent control, error alarm, etc.
With the intelligent master control program, it realizes the automatic and smart soldering process.
Applications:
Electronic Components
PCB
Power StripS
Digital Products
Connectors/Electronic Wires
LED Lighting
LCD monitor/Display Module
Cellphone & Accessories
Basic Configuration:
Applicable for different products, soldering temperature can be set freely.
(Different temperature can be set for each solder joint.)
The soldering iron unit can be multi-directionally adjusted, which can protect the PCB and components from damage.
Numerically controlled temperature. ( static air condition +-1℃)
With the handheld LCD teaching pendant, the programming is simple and easy to learn.
In the soldering process, the solder tip has rapid heat recovery and a long life span.
1.We are a leading manufacturer of Soldering Robot and we controll Robot in high quality!
2. We can also customize the products to fulfill different requirements.
3. Credibility: We are the 7th year Alibaba Gold Supplier. Our customers are located all over the world.
4. Gratitude: We cherish and feel grateful to every customer for the business you give us. We are your reliable partner and will return to you with good products and good support.
5.Professional: We have been in this business for more than 10 years. We have a strong professional team with various experiences.
6.We keep doing new product development. Our goal is to enhance our competitive capacity constantly.
7. Price: we always offer competitive prices and help our customers to cost down.
8. Quality: we do 100% inspection before the shipment.
9.Promise: we are always ready to shoulder the responsibility if any loss caused to our customer due to our mistakes.
10. We also supply a wide range of products and provide one-stop service for Electronic Assembly Industry.
Q1: Why do you buy the soldering robot from us?
A1: 1. Compare with the apolo seiko soldering robot, our price is only one third to one fifth.
2. and our quality is not much different with apollo seiko soldering robot.
We adapt with the Apollo Seiko heating controller system and technology.
3. The consumable soldering robot tips is low cost, and you can also use the original apollo seiko soldering robot tip for our robot.
| Model | S514 soldering robot |
| Package | 1set/exported case |
| Weight | about 92kg |
| Delivery | 3-5 days |
| Payment | Bank, Westerun Union, Paypal |
| Port | Shenzhen |
| Shipment | A.By Courier: 4-7 Working days by special offer |
| B.By Air: 7 Working days at appointed airport | |
| C.By Sea: 20-25 Working days at appointed port |
