HY-300YY Desktop Soldering Robot Automatic Soldering Robot
---- You also could choose the model best suited for your work
| Soldering Robot | HX-300YY |
| Voltage | 110V/220V AC |
| Heating Power | 150-300W |
| Preheating Temperature Range | 0℃-550℃ |
| Axis | 6 Axis |
| Operating Range | 500mm x 300mm x 80mm (X*Y*Z) |
| Movement Speed | X*Y Axis: 0.1~600mm/s, Z Axis:0.1~400mm/s |
| Repeatability Accuracy | ±0.02mm (X*Y*Z) |
| Min. Analysis | 0.01mm (X*Y*Z) |
| Max. Load Weight | 8kgs (for work platform) |
| Program Capacity | Max.255 programs |
| Solder Wire Diameter | 0.5,0.6,0.8,1.0,1.2 (mm) |
| Operating Temperature | 10℃-40℃ |
| Operating Humidity | 20-90% |
| External Dimensions | 870 x 630 x 830mm |
| Weight | about 92 kgs |
Description:
Soldering Robot provides the best solution for soldering job on lead-free,heat dissipating PCB, and high thermal capacity components. It is suitable for all sorts of difficult soldering tasks and micro soldering process. It effectively improves the soldering quality and consistency. Besides, it saves 30% of the solder consumption comparing to manual soldering.
Applications:
Smartphone: Soldering Robot support manufacturing methods suited to a variety of surface mount components and are also widely used for micro-scale soldering
LED Terminals:Soldering Robot offer proper component support and are capable of soldering at the appropriate temperature for difficult to solder LED light terminals and power supply PCBs
Automotive Electronics: Soldering Robot support safety and high reliability soldering for Electronic compoents in motor vehicles.
Basic Configuration:
2) With the sleeve design, the soldering tip can be replaced quickly and easily;
3) Intelligent solder feeding mode, parameters can be set freely;
4) Automatic tip cleaning function by airflow cleaning, the residual dross on the tip can be blown off easily
1.We are a leading manufacturer of Soldering Robot and we controll Robot in high quality!
2. We can also customize the products to fulfill different requirements.
3. Credibility: We are the 7th year Alibaba Gold Supplier. Our customers are located all over the world.
4. Gratitude: We cherish and feel grateful to every customer for the business you give us. We are your reliable partner and will return to you with good products and good support.
5.Professional: We have been in this business for more than 10 years. We have a strong professional team with various experiences.
6.We keep doing new product development. Our goal is to enhance our competitive capacity constantly.
7. Price: we always offer competitive prices and help our customers to cost down.
8. Quality: we do 100% inspection before the shipment.
9.Promise: we are always ready to shoulder the responsibility if any loss caused to our customer due to our mistakes.
10. We also supply a wide range of products and provide one-stop service for Electronic Assembly Industry.
Q1: Are you manufacturer, and are you make the Robot yourselves?
A1: Yes, we make Soldering Robot,Screw Fastening Robot and Glue Dipenseing Robot ourselves! Warm welcome to inquiry!
| Model | HY-300YY soldering robot |
| Package | 1set/exported case |
| Weight | about 92kg |
| Delivery | 3-5 days |
| Payment | Bank, Westerun Union, Paypal |
| Port | Shenzhen |
| Shipment |
A.By Courier: 4-7 Working days by special offer |
| B.By Air: 7 Working days at appointed airport | |
| C.By Sea: 20-25 Working days at appointed port |
