Benchtop Automated dispensing robot Automated dispensing systems
Specification:
| Model | GD-300 | GD-400 | GD-500 |
| Work Area | 300(X) x 300(Y) x 100(Z)mm | 400(X) x 400(Y) x 100(Z)mm | 500(X) x 500(Y) x 100(Z)mm |
| Size | 490(L) x 528(W) x 679(H)mm | 590(L) x 628(W) x 679(H)mm | 690(L) x 728(W) x 679(H)mm |
| Y/Z(Max load) | 7kg/3kg | ||
| Travel speed | 400mm/(XY)/200mm/(Z) | ||
| Drive mode | Stepping motor+belt+precise linear guide rail | ||
| XYZ Repeatability | ±0.03mm | ||
| Program capacity | 999 parameter files(capacity 65535 points per file) | ||
| Operation system | LCD panel /Teach pendant | ||
| Motor | Japan micro stepping motor | ||
| Movement pattern | 3 axes point to point,continuous line, arc | ||
| I/O signal ports | 4 inputs/4 outputs | ||
| Power supply | AC220V 50/60Hz 0.5kw | ||
| Work condition | Temperature 0-40°C;humidity 20-90% | ||
| Weight | 35KG(About 35KG) | 45KG(About 45KG) | 55KG(About 55KG) |
Feature:
2.Save labor cost and avoid the production effect caused by workers
3.Save glue consumers, it saves 30% of glue than manual glue dispensing
4.One operator can operate several machines at the same time
5.Easy to stall, save space.
Main Functions:
bonding,sealing,filling,coating,pouring., etc - drawing points, lines, surfaces, arcs, cycles and consecutive interpolation of irregular curve and so on to realize any 3D non-planar trajectory path
Applicable dispensing material:
UV glue, instant glue, silica gel, hot melt adhesive, red glue, silver glue, AB glue, EPOXY resin, COB black glue, white glue, conductive glue, thermal paste, solder paste, transparent paint, etc.
Advantages:
1. LCD Teach Pendant.
2. Supporting array, graphic browsing, 3D arc, common graphic library inserting and group editing
3. Mini SD files memorizer high speed and 2G capacity
4. Automatic gel prevention to prevent glue curing to jam nozzle
5. Support Auto CAD, Coral Draw, etc to generate formats (such as NC, AI, DXF, JPG, BMP, scanner,etc.)
Configurations:
| Title | Unit | Q'ty | Remark |
| Motor | kit | 3 | Micro stepping motor |
| High precision dispensing valve | pc | 1 | Optional |
| Movement controller kit 1 | kit | 1 | automatic |
| Automatic dispensing software kit 1 | kit | 1 | independent R&D |
| Precise dispensing controller kit 1 | kit | 12 | Optional |
1.We are a leading manufacturer of Automated dispensing robot, Screw fastening robot, Soldering Robot ! Our advanced technology and high quality has gained our leading position in the automatic industry.
2.Professional: With Own Technology, we have been in this business for more than 13 years. We have a strong professional team with various experiences.
3. We can also customize the products to fulfill different requirements.
4.Quality: we do 100% inspection before the shipment.
5. Price: we always offer competitive prices and help our customers to cost down.
6. Promise: we are always ready to shoulder the responsibility if any loss caused to our customer due to our mistakes.
7. We keep doing new product development. Our goal is to enhance our competitive capacity constantly.
8. Gratitude: We cherish and feel grateful to every customer for the business you give us. We are your reliable partner and will return to you with good products and good support.
Q: Why choose us?
1.High grade configuration
2.Leading glue dispensing technology
3.Cost-effective glue dispensing consumers
4.With production and researching experience over a decade
5.Meet customer’s requirements to fit the production environment
Q: What your dispensing robot advantage ?
1. Our glue dispensing controller is with faster dispensing speed and more accurate dispensing.
2. We mold for glue dispensing consumers such as barrels, needles by ourselves, saving cost and cost-effective.
3.The core parts is manufactured by worldwide famous components, ensuring high quality and stable performance.
| Model | Dispensing robot |
| Package | 1set/exported case |
| Weight | 35kg -55 kg |
| Delivery | 3-5 days |
| Payment | Bank, Westerun Union, Paypal |
| Port | Shenzhen |
| Shipment | A.By Courier: 4-7 Working days by special offer |
| B.By Air: 7 Working days at appointed airport | |
| C.By Sea: 20-25 Working days at appointed port |
