YUMO S-75 12/24/48V 75W Single output High efficiency power supply Switching Power Supply
Specifications:
1.CE RoHS approved
2.2 years warranty
3.high quality
4.79% efficiency
Notice:
a.We do have enough ability to produce your customized order
b.Samples are available
c.High quality and competive price .
d 2 years warrenty ,buy with confidence
General Specification :
Model | S-75-12 | S-75-15 | S-75-24 | S-75-48 |
DC output voltage | 12V | 15V | 24V | 48V |
Rated output current | 6A | 5.0A | 3A | 1.5A |
Output current range | 0-6A | 0-5A | 0-3A | 0-1.5A |
Wave and noise | 75mVp-p | 100mVp-p | 100mVp-p | 100mVp-p |
Inlet stability | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
Load stability | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
Efficiency | 78% | 79% | 82% | 83% |
Adjustable range for DC voltage | ±10% | ±10% | ±10% | ±10% |
AC input voltage range: | 85~132VAC/170~264VAC selected by switch 47~63Hz;240~370VDC | |||
AC inrush current: | Cold-start current 15A/115V 30A/230V | |||
Overload protection: | 105%~150% Type:plusing hiccup shutdown Reset:auto recovery | |||
Setup rise hold-up time: | 200ms,50ms,20ms | |||
Withstand voltage:Input and output internal: | 1.5KvAC,Output and enclosure:0.5KvAC | |||
Isolation resistance: | Input and output internal,input and enclosure,output and enclosure:500VDC/100MΩ | |||
Working temperature | 0~50°C | |||
Safety standards: | GB4943 UL60950 EN60950 | |||
EMC standards: | EN55022 GB9254,class A | |||
Overall dimension: | 159*97*38mm | |||
Weight: | 0.56Kgs | |||
