Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > YUMO S-350 350W 5/12/48V Single Output High Efficiency Power Supply Switching Power Supply

YUMO S-350 350W 5/12/48V Single Output High Efficiency Power Supply Switching Power Supply

Yueqing Yings Import & Export Co., Ltd.
YUMO S-350 350W 5/12/48V Single Output High Efficiency Power Supply Switching Power Supply thumbnail-1
YUMO S-350 350W 5/12/48V Single Output High Efficiency Power Supply Switching Power Supply thumbnail-2
YUMO S-350 350W 5/12/48V Single Output High Efficiency Power Supply Switching Power Supply photo-1
YUMO S-350 350W 5/12/48V Single Output High Efficiency Power Supply Switching Power Supply photo-2
US$ 23 - 27 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YUMO
Model Number:
S-350
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name YUMO
Model Number S-350
Output Power Other, 250-400W
Output Type Single
Input Voltage Other, 90-264VAC
Output Voltage 5-48V
Output Frequency 37KHz
Output Current 8.3-50A

  YUMO S-350 350W 5/12/48V Single output High efficiency power supply Switching Power Supply



Product Description



Specifications:

350w s-350-48 switching power supply
1.two years warranty
2.CE,ROHS approved
3.86% efficiency
4.110/220VAC input
power supply for camera
Notice:
a.We do have enough ability to produce your customized order
b.Samples are available
c.High quality and competive price .
d.2 years warrenty ,buy with confidence
1.Features:
1. AC input range selectable by switch
2. Protections: Short circuit / Overload / Over voltage / Over temperature
3. 100% full load burn-in test
4. Low cost, high reliability
5. 24 months warranty


General Features:

Model

S-350-5

S-350-12

S-350-15

S-350-24

S-350-27

S-350-48



output

DC voltage

5V

12V

15V

24V

27V

48V



Voltage tolerance

±2%

±1%

±1%

±1%

±1%

±1%



Rated current

50A

29A

23.2A

14.6A

13A

8.3A



Current range

0~50A

0~29A

0~23.2A

0~14.6A

0~13A

0~8.3A



Rated power

250W

348W

348W

350.4W

351W

398.4W



Ripple&noise

100mvp-p

150mvp-p

150mvp-p

150mvp-p

150mvp-p

200mvp-p



DCvoltage ADJ.range

-9%~+10%

±10%

±10%

±10%

±10%

±10%



input

Voltage range

90~132VAC/180~264VAC(selected by switch),255~373VDC



frequency

47~63HZ



AC current

6.5A/115VAC,4.0A/230VAC



efficiency

78%

80%

80%

82%

82%

83%



Inrush current

Cold start current 25A/115VAC,50A/230VAC



Leakage current

< 3.5mA/240VAC



protection

overload

Rated output power105%~135%  start over load protection



protection type :rated current limit ,auto-recovery after fault condition is removed



Over voltage

6.8~8.2V

15.6~17.8V

18.6~20.8V30.6~33.2V

33.2~35.6V

54.8~56.6V



Protection type:hiccup mode,auto-recovery after fault condition is removed

Over temperature

≥55℃fan on,≤50℃fan off,≥85℃ start over temperature protection

Protection mode:cutoff output,auto-recovery after temperature become normal

environment

Working temp,humidity

-10℃~+60℃,20%~90%RH

Storagetemp,humidity

-20℃~+85℃,10%~95%RH non-condensing

Withstand vibration

10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes

safety

Withstand voltage

I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC

Isolated resistance

I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC

Fitstandard

Safety standard

Fit UL1012

EMC standard

EN55022,CLASSA

others

Dimension

215*115*50mm (L*W*H)

Weight/packing

1.0kg/24pcs/25kg/0.049 m³/1.72CUFT

note

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.
