YUMO SP-500 500W 12/24/48V Single Output High Efficiency Power Supply Switching Power Supply

Yueqing Yings Import & Export Co., Ltd.
YUMO SP-500 500W 12/24/48V Single Output High Efficiency Power Supply Switching Power Supply thumbnail-1
YUMO SP-500 500W 12/24/48V Single Output High Efficiency Power Supply Switching Power Supply photo-1
US$ 65 - 69 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
YUMO
Model Number:
SP-500
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name YUMO
Model Number SP-500
Output Power Other, 480-500W
Output Type Single
Input Voltage Other, 85-267VAC
Output Voltage 12-48V
Output Frequency 37KHz
Output Current 10-40A

YUMO SP-500 500W 12/24/48V Single output High efficiency power supply Switching Power Supply



Product Description

Specifications:

SP-500-12
1. CE ROHS approved
2. AC85~264V 120~370VDC input
3. 84% efficiency
4.2 years warranty
Notice:
a.We do have enough ability to produce your customized order
b.Samples are available
c.High quality and competive price .
d. 2 years warrenty ,buy with confidence


General Features:

Model
Specification

SP-500-12

SP-500-13.5

SP-500-15

SP-500-24

SP-500-27

SP-500-48

DC output voltage

12V

13.5V

15V

24V

27V

48V

Output voltage error

±1%

±1%

±1%

±1%

±1%

±1%

Rated output current

40A

36A

32A

20A

18A

10A

Output current rage

0-40A

0-36A

0-32A

0-20A

0-18A

0-10A

Wave and noise

240mVp-p

240mVp-p

240mVp-p

240mVp-p

200mVp-p

300mVp-p

Inlet stability

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

Load stability(Note5)

±1%

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

DC output power

480W

486W

480W

480W

486W

480W

Efficiency

84%

84%

83%

85.5%

86.5%

87%

Adjustable range for DC voltage

10-13.2V

12-15V

13.5-18V

20-26.4V

24-30V

41-56V

AC input voltage range

88132VAC/176264VAC BY SWITCH 4763Hz;124370VDC

AC Input current

7A/115V 3.5A/230V

Power Factor

0.95/100240VAC

AC impulse current

18A/115V 36A/230V

Leakage current

<3.5mA/240VAC

Overload protection

105%135% TypePULSING HICCUP SHUTDOWN Reset: auto recovery

Over-voltage protection

13.816.2V

15.518.2V

1821V

27.632.4V

3136.5V

57.667.2V

Fan control,O.T.P.

RTH1 OR RTH2>=50 FAN ON,<=45 FAN OFF,>=70 Cut off output

Temperature coefficient

±0.03%(050)

Setup rise hold up time

1.5s,50ms,20ms

Vibration

10500Hz,2G 10min./1cycle,Period for 60min,EACH AXES

Withstand voltage


Input and output interval3KVAC,Input and enclosure1.5KVAC Output and enclosure0.5KVAC

Isolation resistance

Input and output interval,Input and enclosure,Output and enclosure500VDC/100M Ohms

Working temperature and humidity

-10+50,20%90%RH

Store temperature and humidity

-20+85,10%95%%RH

Overall dimension

185*20*93mm

Weight

1.8Kgs

Safety standards

UL1950,TUV EN60950

EMC standards

IEC1000-42,3,4,5,6,8,11 IEC100-3-2
