Fire Fighting Equipment With Radiator Manufacturers 6102BZSS

Name: Fire Fighting Equipment With Radiator Manufacturers 6102BZSS
Brand: HALOTOP
SKU: 141199284
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

HALOTOP

Model Number:

6102BZSS

Shanghai Halotop Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name HALOTOP

Model Number 6102BZSS

Specifications

Fire fighting equipment with radiator manufacturers 6102BZSS
with shaft, radiator , air fliter,muffler,solenoid valve.

Product Description

Fire fighting equipment with radiator manufacturers 6102BZSS

Fire fighting equipment / fire fighting equipment manufacturers / fire fighting equipment supplier

HEAT EXCHANGER SERIES -DIESEL ENGINE
Engine Model		380	485	4100	6102BQ	6102BZSS	6120TI
Type		Vertical,water-cooling 4-stroke,direct-injector
Aspiration		Nature				Turbo-charged
Number of Cylinders		4	4	4	6	6	6
Bore*Storke(mm)		80*90	85*90	100*118	102*118	102*118	120*130
Compression Ratio		18:01	18:01	18:01	17:01	17:01	16.5:1
Total Displacement(L)		1.357	2.156	3.705	5.78	5.78	8.82
Rated Power	KW/HP	20/27	33.5/45	56/75	95/130	138/187	200/272
Rated Speed	r/min	3000	3000	3000	3000	3000	2200
Max.torque	N.m	≥72.6	≥118.2	≥193	≥332.6	≥483
Fuel Consumption	g/kW.h	≤242	≤241	≤238	≤205	≤205	≤200
Heat changer		CH100	CH200	RD4100	RD6102	RD6102	CH700
Rotating Direction at Output End		Counter-clockwise
Lubrication Oil		15W40
Lubrication Oil Content	L	4.5	6.5	9	13	13	24
Lubrication Method		Pressure and splash
Starting Method		Electric
PTO Type		Option:1.Shaft2.Coupling3.Drive Plate
Net Mass	kg	250	320	420	650	720	1100
