Diesel Engine for Fire Fighting Training Equipment With Radiator 4105T
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HALOTOP
Model Number:
4105T
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
20KW 3 Cylinders New Fire Fighting Equipment With Radiator 380 SupplierNegotiableMOQ: 1 Set -
58HP Diesel Engine for Fire Fighting With Radiator 490NegotiableMOQ: 1 Set
-
45HP New Fire Fighting Diesel Engine With Radiator 485NegotiableMOQ: 1 Set
-
45HP New Fire Fighting Training Equipment With Radiator 485NegotiableMOQ: 1 Set
-
4 Cylinders Diesel Engine Fire Fighting Equipment With Radiator 4100NegotiableMOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
HALOTOP
Model Number
4105T
Specifications
Diesel engine for fire fighting training equipment with radiator 4105Twith shaft, radiator, air fliter,muffler,solenoid
Product Description
Diesel engine for fire fighting training equipment with radiator 4105T
Diesel engine for fire fighting / diesel engine / fire fighting training equipment
| Engine Model | 380 | 480 | 4100 | 4105T | 6102BZS | |
| Type | Vertical,water-cooling 4-stroke,direct-injector | |||||
| Aspiration | Nature | Turbo-charged | ||||
| Number of Cylinders | 4 | 4 | 4 | 4 | 6 | |
| Bore*Storke(mm) | 80*90 | 85*90 | 100*118 | 105*118 | 102*118 | |
| Compression Ratio | 18:01 | 18:01 | 18:01 | 17.5:1 | 17:01 | |
| Total Displacement(L) | 1.357 | 1.809 | 3.705 | 4.085 | 5.78 | |
| Rated Power | KW/HP | 20/27 | 27.8/37 | 56/75 | 90/122 | 125/170 |
| Rated Speed | r/min | 3000 | 3000 | 3000 | 3000 | 3000 |
| Max.torque | N.m | ≥72.6 | 99.8 | ≥193 | ≥315 | ≥438 |
| Fuel Consumption | g/kW.h | ≤242 | ≤241 | ≤238 | ≤238 | ≤205 |
| Radiator | RD480 | RD480 | RD4100 | RD4105T | RD6102 | |
| Rotating Direction at Output End | Counter-clockwise | |||||
| Lubrication Oil | 15W40 | |||||
| Lubrication Oil Content | L | 4.5 | 6 | 9 | 11 | 13 |
| Lubrication Method | Pressure and splash | |||||
| Starting Method | Electric | |||||
| PTO Type | Option:1.Shaft2.Coupling3.Drive Plate | |||||
| Net Mass | kg | 250 | 300 | 420 | 500 | 720 |
