4 Cylinders ul Diesel Engine for Fire Fighting Equipment With Radiator 480
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
HALOTOP
Model Number:
480
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fire Fighting Equipment With Radiator Manufacturers 6102BZSSNegotiableMOQ: 1 Set -
Diesel Engine for Fire Fighting Training Equipment With Radiator 4105TNegotiableMOQ: 1 Set
-
20KW 3 Cylinders New Fire Fighting Equipment With Radiator 380 SupplierNegotiableMOQ: 1 Set
-
58HP Diesel Engine for Fire Fighting With Radiator 490NegotiableMOQ: 1 Set
-
45HP New Fire Fighting Diesel Engine With Radiator 485NegotiableMOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
HALOTOP
Model Number
480
Specifications
4 cylinders fire fighting equipment with radiator 480with radiator, air fliter,muffler,solenoid valve.
Product Description
4 cylinders ul diesel engine for fire fighting equipment with radiator 480
diesel engine for fire fighting / 4 cylinders fire fighting equipment / ul fire fighting equipment
| Engine Model | 380 | 480 | 4100 | |
| Type | Vertical,water-cooling 4-stroke,direct-injector | |||
| Aspiration | Nature | |||
| Number of Cylinders | 4 | 4 | 4 | |
| Bore*Storke(mm) | 80*90 | 85*90 | 100*118 | |
| Compression Ratio | 18:01 | 18:01 | 18:01 | |
| Total Displacement(L) | 1.357 | 1.809 | 3.705 | |
| Rated Power | KW/HP | 20/27 | 27.8/37 | 56/75 |
| Rated Speed | r/min | 3000 | 3000 | 3000 |
| Max.torque | N.m | ≥72.6 | 99.8 | ≥193 |
| Fuel Consumption | g/kW.h | ≤242 | ≤241 | ≤238 |
| Radiator | RD480 | RD480 | RD4100 | |
| Rotating Direction at Output End | Counter-clockwise | |||
| Lubrication Oil | 15W40 | |||
| Lubrication Oil Content | L | 4.5 | 6 | 9 |
| Lubrication Method | Pressure and splash | |||
| Starting Method | Electric | |||
| PTO Type | Option:1.Shaft2.Coupling3.Drive Plate | |||
| Net Mass | kg | 250 | 300 | 420 |
