Specifications
1. material: LDPE, LLDPE, EVA, and mPE2. multilayer
3. dike type, steady wind structure
4. wind-up speed: 3-30m/min
Structural characteristics
It mainly adopts advanced technologies of high-efficiency and energy saving extruding system, rotating die head, elevation type haul-off, and automatic temperature control system. The die head and the screw are processed by imported processing center.
Three layers co-extruding composition plastic packaging film machine unit is mainly used for producing LDPE, LLDPE, EVA, and mPE three-type three-layer, two-type three-layer and one-type three-layer composition films. It is the ideal equipment for producing various fluid packaging film, printing film and black/white films.
Main technical parameters:
Model |
3FM1100-I |
3FM1300-I |
3FM1600-I |
3FM2200-I |
Max. folding width MM |
1,000 |
1,200 |
1,500 |
2,000 |
Applicable raw material |
LLDPE, LDPE, LLDPE/LDPE Blend, mPE, EVA |
|||
Composed layers |
3 |
3 |
3 |
3 |
Screw dia. |
Φ45/Φ45/Φ45 |
Φ45/Φ45/Φ45 |
Φ50/Φ50/Φ50 |
Φ55/Φ55/Φ55 |
Max. plasticizing capacity |
120kg/h (LDPE) |
120kg/h (LDPE) |
160kg/h (LDPE) |
200kg/h (LDPE) |
Die head |
Φ200 |
Φ300 |
Φ350 |
Φ500 |
Air ring |
Dike type, steady wind structure |
|||
Length of haul-off roller |
1,100 |
1,300 |
1,600 |
2,200 |
Wind-up speed |
3~30m/min |
|||
Total power kw |
90 |
92 |
110 |
135 |
Overall dimension |
9×5.5×6.5 |
9×5.7×6.5 |
9×6.5×7 |
9×7.5×8 |
Weight tons |
12 |
12.5 |
14 |
16 |
