Specifications
1. raw material: LDPE, LLDPE, EVA, and mPE2. Layers: 3
3. Composition films
4. Wind-up speed: 3~30m/min
Q: Why choose Hengxiang? Any advantages?
A: The answer is Yes. There are5 advantages.
(1) MUTUAL BENEFIT: Our offer will be reasonable, our price will be cheaper in the same quality.
(2) CUSTOMIZE: We can make the product as your request, Shape and Quality can meet your request.
(3) MIX ORDER: We accept mix order, different model and small quantity order.
(4) AFTER SERVICE: (1)5 Years Guarantee. (2)If some parts are broken, we will send new parts to repair after confirmed.
Q: Can I order one piece for sample to test the quality?
A: Yes, We recommend to check the sample before order.
Q: May I have your catalogue and price list for trial order in MOQ quantity?
A: All our products were shown on alibaba, please have a detailed looking and choose the interested models in our site.
Q: If I want cheaper quality, can you produce?
A: Yes, just send us your quality details, such as the material, what cheaper parts instead etc, we will do that as your request and calculate the price.
Q: If I order big quantity, what's the good price?
A: Please send the details enquiry to us, such as the Item Number, Quantity for each item, Quality request, Logo, Payment Terms, Transport method, Discharge place etc. We will make the accurate quotation to you as soon as possible.
Thank you for your visiting. Any questions, please feel free to contact us. I am June here.
Skype: juneshuijing1
Structural characteristics
It mainly adopts advanced technologies of high-efficiency and energy saving extruding system, rotating die head, elevation type haul-off, and automatic temperature control system. The die head and the screw are processed by imported processing center.
Three layers co-extruding composition plastic packaging film machine unit is mainly used for producing LDPE, LLDPE, EVA, and mPE three-type three-layer, two-type three-layer and one-type three-layer composition films. It is the ideal equipment for producing various fluid packaging film, printing film and black/white films.
Main technical parameters:
Model | 3FM1100-I | 3FM1300-I | 3FM1600-I | 3FM2200-I |
Max. folding width MM | 1,000 | 1,200 | 1,500 | 2,000 |
Applicable raw material | LLDPE, LDPE, LLDPE/LDPE Blend, mPE, EVA | |||
Composed layers | 3 | 3 | 3 | 3 |
Screw dia. | Φ45/Φ45/Φ45 | Φ45/Φ45/Φ45 | Φ50/Φ50/Φ50 | Φ55/Φ55/Φ55 |
Max. plasticizing capacity | 120kg/h (LDPE) | 120kg/h (LDPE) | 160kg/h (LDPE) | 200kg/h (LDPE) |
Die head | Φ200 | Φ300 | Φ350 | Φ500 |
Air ring | Dike type, steady wind structure | |||
Length of haul-off roller | 1,100 | 1,300 | 1,600 | 2,200 |
Wind-up speed | 3~30m/min | |||
Total power kw | 90 | 92 | 110 | 135 |
Overall dimension | 9×5.5×6.5 | 9×5.7×6.5 | 9×6.5×7 | 9×7.5×8 |
Weight tons | 12 | 12.5 | 14 | 16 |
