Everflying PE Plastic Film Blowing Machine

Name: Everflying PE Plastic Film Blowing Machine
Brand: Hengxiang
SKU: 141185382
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Film

Plastic Processed:

Laiwu Everflying Plastic Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Film

Plastic Processed PE

Blow Moulding Type Extrusion Blow Moulding

Automatic No

Place of Origin Shandong, China

Brand Name Hengxiang

Certification ISO9001

After-sales Service Provided Overseas service center available

Specifications

It is used for producing packing films .The products are widely used for the package of foodstuffs, drugs,boxes,and bottles ect.

Product Description

It also can used for producing LDPE,LLDPE,HDPE film,packing film,wrapping

film,water-proofing and seepage prevention films after changed the screw and

machine head.

Main technical parameters:

Extruder	Lower center
Screw dia. mm	35	45	50	55	65	75
L/D	30:1
Main motor KW	15	18.5	22	30	37	45
Rotating speed R/Min	0~120	0~120	0~120	0~120	0~100	0~100
Heating power KW	7	8.5	10	12	14	18
Temperature control sections	3	5	5	5	7	7
Die head	Spiral head
Applicable raw material	HDPE, LDPE, LLDPE
Film width mm	100~550	150~700	200~750	300~950	400~1,150	500~1,450
Film thickness mm	0.008~0.2
Extruding capacity Kg/h	10~30	15~60	15~75	20~90	25~120	30~145
Total power KW	28	42	45	48	60	80
Net weight Kg	2,500	2,800	3,000	3,200	4,000	5,000
Dia. of neckling die mm	HL40	HL60	HL80	HL80	HL100	HL130
Dia. of neckling die mm	L120	L150	L150	L200	L250	L300
Heating power KW		3/4	3/4	3/4.2	3.5/5	3.5/6
Blower power KW	2.2			4
Air ring	1
Haul-off machine	Automatic haul-off
Haul-off power KW	0.75		1.1			1.5
Width of haul-off roller mm	600	750	800	1,000	1,200	1,500
Haul-off speed m/min	12~120
Haul-off height mm	4,000	4,200	4,200	4,500	5,000	5,500
Coiler	Surface friction coiler
Coiling position	Single position (or double positions)
Motor Kg/cm	10	15	20	20	30	40
Coiling width mm	650	800	850	1,050	1,250	1,550
Inner dia. of the paper pipe mm	70
Outer dia. of the paper pipe mm	90
Dimension m	1.8×3.6	2.0×4.0	2.1×4	2.2×4.2	2.2×4.8	2.6×5.0
