600A Welding Machine Diesel Generator

Name: 600A Welding Machine Diesel Generator
Brand: Huatian
SKU: 141184900
Availability: InStock

US$ 1,000 - 10,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Huatian

Model Number:

30kw

Weifang Huatian Diesel Engine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Huatian

Model Number 30kw

Output Type AC Three Phase

Speed 1500/1800rpm

Frequency 50/60Hz

Rated Power 30kw

Rated Voltage 400/230V

Rated Current 54.1A

Specifications

1)600A Welding generator
2)new design,silent type,good view. low oil.
3)One year/2000 hours warranty
4)3-Phase 4-wire

600A Welding generator Data,

Primary Competitive Advantages:

Main Export Markets:

Key Specifications/Special Features:

Dual-purpose DC electric welder and AC generator
Welder and generator are independent of each other, preventing mutual interference
Current can be remotely controlled
Both three-phase and single-phase outputs available
Noise can be less than 80dB at 1m
Total power range extends from 15kW (welder 10kW, generator 5kW) to 100kW (welder 40kW, generator 60kW)
Current range: 50 to 500A
Suitable for the welding rods with diameters from 1.5 to 8mm
Welding outputs can be 1 to 4 roads, enabling simultaneous welding works
Engines fitted include DEUTZ engines and Chinese engines
Cooling methods include water-cooling and air-cooling
Air-cooling models are suitable for drought and water-lack areas
Structure types include open-frame type, silent type, trailer type and rainproof type
Generator has both three-phase and single-phase outputs (50/60Hz)
Excitation is brushless with AVR fitted
Power factor is 0.8 lagging
Steady voltage regulation: within ±1%
Transient voltage regulation: -15 to +20%
Transient voltage recovery time: ≤1s
Steady frequency regulation: within ±3%
Transient frequency regulation: within ±10%
Transient frequency recovery time: ≤3s
Voltage fluctuation (tolerance): within ±0.5%
Voltage waveform distortion: ≤2.5%
Voltage unbalance under unbalanced loads: ≤;3%
Insulation: class H (125K)
