US$ 5,000 - 6,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Usage:
Other, Generator
Fuel:
Diesel
Stroke:
4 Stroke
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
R4105ZD Diesel Generator Engine 56kwUS$ 1 - 1,000MOQ: 1 Set -
132kw Diesel Engines R6105IZLD 1500/1800 R/minUS$ 1 - 10,000MOQ: 1 Set
-
2 Years Warranty 10kw-500kw Deutz Stamford Marine GeneratorUS$ 1,900 - 5,000MOQ: 1 Set
-
Weifang Diesel Engine Part 295/495/4100/4105/6105/6113/6126 Engine PartsUS$ 5 - 100MOQ: 1 Piece
-
Weichai Power WD615 Deutz 226B Diesel Engine Generator Spare PartsUS$ 1,000 - 10,000MOQ: 1 Piece
Usage
Other, Generator
Fuel
Diesel
Stroke
4 Stroke
Cylinder
Multi-cylinder
Cold Style
Other, Water-cooled
Start
Electric Start
Place of Origin
Shandong, China
Brand Name
HT-Steyr
Model Number
6126ZLC
Specifications
11)Marine Engine with Austria Technology2)310hp/1500rpm
3)Water Cooling
4)Lifetime Service
5)2years Warranty
1,Marine Engine Details,
| Engine Model | 6113ZD | 6113ZLD | 6126.00D2 | 6126.61D-15 | 6126.64D-16 | 6126.68D-15 | 6126.68D-1 | 6126.68D-2 | ||
| Type | 4 Strokes, Water Cooling, Inline, Direct Injection Combustion Chamber | |||||||||
| Rated Power/Speed(kw/rpm) | 100/1500 | 142/1500 | 86/1500 | 117/1500 | 138/1500 | 170/1500 | 215/1500 | 248/1800 | ||
| Cylinder Number | 6 | |||||||||
| Bore*Stroke | 113*125 | 126*130 | ||||||||
| Total Displacement of Piston(L) | 7.552 | 9.726 | ||||||||
| Pressure Ratio | 17.5 | 16 | ||||||||
| Firing Order | 1-5-3-6-2-4 | |||||||||
| Air Intake Type | Turbo. | Naturally Asp. | Turbo. | |||||||
| Fuel Consumption(g/kw.h) | 215 | 208 | 238 | 224 | 215 | 208 | 218 | 218 | ||
| Oil Consumption(g/kw.h) | 1.63 | |||||||||
| Exhaust Temperature | 600 | |||||||||
| Crankshaft ratating) | Inverse Hour(Facing to the power output end) | |||||||||
| Cooling Mode | Forced Cooling | |||||||||
2, We can make the marine engines with different functions, according to customers's requirements.
Used for marine generator or marine.
3, Accessories,
With Sea water and fresh water exchanger.
With sea water and fresh water pump.
Stop Solid and Protection can be optional.
Any Colour can be optional.
1500rpm,1800rpm, and 2000rpm can be optional.
Gearbox can be optional.
4,Business Term,
Warranty:2 Years.
Delivery:10-20days.
Payment: T/T and L/C.
Minimum Order Quantity: 1 Set.
Sincerely waiting for your inquiry and further cooperation!
|
|
|
