High head submersible slurry sump pump for mining and washing coal
High head submersible slurry sump pump application
The vertical slurry pump is widely used in delivery slurry with solids in electric power, metallurgy, coal, building material and other industries. Such as hydraulic removing ash for thermal power plants, pump mill slurry in metallurgy delivery coal slurry and heavy slurry for coal.
Typical application:
Mine: black, colored slurry feed pump and delivery for kinds of concentrates and tailings;
Metallurgy: transport of various kinds of aluminum and steel mill slurry;
Coal: delivery for coal mining, washing, all kinds of coarse and fine coal slurry;
Electricity: transport for power plant ash, ash washing, various ash slurry, or mortar;
Building Materials: delivery for all kinds of including sediment slurry (such as cement plant slurry);
Chemical: delivery of phosphate fertilizer, potash fertilizer plant all kinds of abrasive slurry;
Water Works: lake, river dredging, sediment, gravel, clay high plastic suction and discharge.
In the mine site pump station
Drainage slurry working condition
High head submersible slurry sump pump introduction
BP(R) pump is centrifugal vertical sump pump, work under fluid. It widely used for delivery abrasive, high density slurry with large particle in the metallurgy, mine, power plant, chemical, and other industry.
Feature
Vertical type
Semi-opening impeller
Sufficient strength
No bearing between bare pump and impeller
Transfer bigger solids
High working temperature
Size (discharge): 1" to 18" (25 mm - 450 mm)
Capacity: To 3400 m3/hr
Head: T0 120 m
Particle Size: To 260 mm
Concentration: To 60%
Material:SS,A03,A07,A51,etc
Detailed specification
1.Cantilevered shaft design
2.Double suction semi-open impeller
3.Agitator option keeps solids in suspension
4.models feature full rubber covering for corrosion resistance
5.Recessed impeller option passes oversized material
6.Fully elastomer lined or hard metal fitted. No submerged bearings or packing. High capacity double suction design. Optional recessed impeller and suction agitator available.
7.No submerged bearings or packing. High capacity double suction design. Optional recessed impeller and suction agitator available.
High head submersible slurry sump pump parameter
Models | |
(Metal Pump) | (Rubber Pump) |
40C-BP | 40C-BPR |
65D-BP | 65D-BPR |
100E-BP | 100E-BPR |
150F-BP | 150F-BPR |
200F-BP | 200F-BPR |
250S-BP | 250S-BPR |
300S-BP | 300S-BPR |
(Sheet 1) | |
High head submersible slurry sump pump curve
High head submersible slurry sump pump structure
1. Material construction optional
BP: abrasion resisting metal construction
BPR: anti-corrosive rubber construction
2. Do not need any shaft seal or sealing water
Also worked well under insufficient suction duty.
3. The type with “L” is the pump with extension shaft
It suitable to deep condition. It has guid bearing. So it more stable and used more wide. However the flushing water is necessary on the guide bearing part.
4. The agitator is available
We can assembly the agitator as requirements.
High head submersible slurry sump pump pictures
High head submersible slurry sump pump packing and shipping
