Centrifugal Vertical Sump Pump, Slurry Pump, Available From Stock.

Shijiazhuang An Pump Machinery Co., Ltd.
Centrifugal Vertical Sump Pump, Slurry Pump, Available From Stock. thumbnail-1
Centrifugal Vertical Sump Pump, Slurry Pump, Available From Stock. photo-1
US$ 200 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
An Pump
Model Number:
LBP.LBPR
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name An Pump
Model Number LBP.LBPR
Theory Centrifugal Pump
Structure Single-stage Pump
Usage Other, slurry , mud , sand etc.
Power Other, electric, diesel engine
Standard or Nonstandard Standard
Fuel Other, diesel, gasoline etc
Pressure High Pressure
Application Other, mining , paper industry , cement, plant, sugar, etc.

centrifugal vertical sump pump, slurry pump, available from stock.

centrifugal vertical sump pump, slurry pump, available from stock.



Shijiazhuang An Pump Co.,Ltd



The main pump products include slurry pump,desulfurization pump,gravel pump,sewage pump,impurity pump,split pump with large capacity,Multistage pump with high lift,centrifugal water pump and self priming pump,could meet various requirements of all the customers.



We have many technical and manage outstanding person who are high stuff and seasoned.Our company absorbed new science and technology fruit,empolder series of high level pump products.Energy saving and environmental protection,Efficient and stable,we will try our best to help the users of metallurgy,mining,electric,coal,dredge,desulfurization of thermal power,petroleum chemical,building to  remove difficulties and alleviate sufferings;



Our team has the strong capacity of technology development,we can do the design, choose the model and scheme, setting design etc,we are always concern about users,we can not only meet the users" requirement but also reduce the cost.





LBP, LBPR series vertical sump pump. slurry pump



 Mining Industry Vertical Sump Pump Slurry Pump



LBP and LBPR pumps are vertical, centrifugal slurry pumps submerged in sump to work.

They are designed for delivering abrasive, large particle and high density slurry.

These pumps have no need of any shaft seal and sealing water.

They can also be operated normally for insufficient suction duties.







BP vertical sump pump performance parameters



PUMP MODEL

MATERIAL

CAPACITY
(m3/h)

HEAD
(m)

MAX PARTICLE SIZE
(mm)

SPEED
(rpm)

MAX POWER
(kw)

LINER

IMPELLER

40 BP

M

M

6 - 50

4 - 29

12

1000 - 2200

15

40 BP

RU

RU

5.8 - 64.8

5 - 54

12

1000 - 2200

65 BP

M

M

14 - 120

4 - 33

15

700 - 1500

30

65 BP

RU

RU

10.8 - 149

5 - 49.5

15

700 - 1500

100 BP

M

M

15 - 330

4 - 37

32

500 - 1200

75

100 BP

RU

RU

25 - 360

6 - 49

40

600 - 1200

150 BP

M

M

36 - 648

5 - 37

43

500 - 1000

110

200 BP

M

M

90 - 828

6 - 41

64

400 - 850

110

250 BP

M

M

40 - 1206

7 - 36

64

400 - 750

200

PLEASE NOTE: "M" MEANS METAL MATERIAL. "R" MEANS RUBBER MATERIAL









Wet parts of BP pump are made of abrasive-resistant metal.



The type with ‘L’ is a sump pump of extension shaft series, which is suited for the working condition of deep level.

The guide bearing construction is added to the pump on the the bases the standard pump, so the pump is with both more steady operation and wider application range, but flushing water should be attached to the guide bearing.





Pump Spare Parts



With large quantity of spare parts in stock, our delivery time is generally very short.

centrifugal vertical sump pump, slurry pump, available from stock.







PUMPS



centrifugal vertical sump pump, slurry pump, available from stock.





An Pump.China



centrifugal vertical sump pump, slurry pump, available from stock.





Thanks for your reading.

 If you have any questions or requests, please  contact us without any hesitate.

 We will try the best to help you, offer good pumps, offer good pump solutions
