Motor engine vertical submersible sewage suction slurry Pump
Motor engine vertical submersible sewage suction slurry Pump Description
the Submersible Sewage slurry Pump is designed to handle dirty water and sewage in domestic and civil applications. it is fitted with a stainless steel “single/two channel/vortex” impeller, and is suitable for pumping liquids containing suspended solids,including short fibers. it is particularly recommended for the transfer of domestic sludge, refluent and surface water, water mixed with mud in areas such as: domestic housing, industrial applications and underground car parks.
Motor engine vertical submersible sewage suction slurry Pump Technical Specifications
| Type | AQW |
| Capacity | 2600m3/h |
| Head | 60m |
| Discharge Diameter | 500mm |
| Speed | 2900r/min |
| Efficiency | 86% |
Motor engine vertical submersible sewage suction slurry Pump Structural Characteristics
Cast iron PUMP BODY, with UNI ISO 228/1 gas threaded delivery ports.
Cast iron BASE and MOTOR HOUSING
AISI 304 stainless steel double channel IMPELLER
AISI 304 stainless steel motor shaft (430F up to 0.75kW)
Screws in contact with fluid in Stainless steel. (Optional stainless steel lifting eye)
Three phase motors above 0.75 kW have three thermal cut-outs in the windings, connected in series with the supply cable. They must be correctly connected to the pump control panel by the user.
Supply Cable
Single phase : 10 metres of neoprene HO7 RN-F submersible cable
Three phase: 10 metres of neoprene FG5 OK 4x1.5mm + 2 x 0.5mm
Main Benefits&Advantages
(1)More than 20 years in pumps line.
(2)Warranty for 1 year.
(3)Long-term reliability.
(4)Excellent rag handling.
(5)Sustainable in manufacturing and operations.
(6)Reduced risk of pollution from overflows.
(7)Reduced risk of interruption to services to customers.
(8)Reduced breakdown costs.
Motor engine vertical submersible sewage suction slurry Pump Applications&Usages
- construction of buildings
- residential quarters
- public works
- road traffic and construction
- sewage plants
- small sewage treatment plants
- hospitals and other occasions
- delivery of solid particles and long fibers containing sewage
- waste water
- rainwater transfering
- Standard wooden cases package, if special requirements, should be inform in advance;
- Shipping by sea, by air, by train and truck all available;
- Delivery date: vary from 5-30days according to different model and quantity.
Shijiazhuang An Pump Machinery Co., Ltd is a professional manufacturer of slurry pumps, sewage pumps, clean water pumps, chemical pumps, fire pumps, irrigation pumps; An pump machinery company has its own strong type selection & design, research and development team, assure to provide you efficient, energy saving slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps type design, use and maintenance program.
An pump products slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps and other products are exported to over 90 countries around the world. The application covers many fields, such as dressing ship, tailings transportation, mining pumps, steel & power desulphurization, boiler feed water, construction, irrigation, water conservancy facilities, sewage treatment.
Q1. Are you a manufacturer?
Yes, we have been in centrifugal pumps manufacturing and marketing industry over 32 years.
Q2. What markets do your pumps export to?
Europe, North & South America, SouthEast Asia, Africa, Oceanica, Middle East countries. Our overseas agent in Italy, Russia, Canada, France, America, Middle East, Asia and Africa are gradually improving.
Q3. What information should I let you know if I want to get a quotation?
Please let us know the pump capacity, head, medium, operation situation, quantity, etc. As much as your provide, the precision
and accurate model selection.
Q4. Is it available to print our own brand on the pump?
Totally acceptable as international rules.
Q5. How can I get the price of your pump?
You can connect with us through any of the following contact information. Our personalized service person will respond you within 24 hours.
Send your inquiry details in the below, click"send" now! Send is to earn!
