Diesel Engine Water Pumps
In general, diesel engine water pump complete set will include pump+diesel engine+ PTO
(power take off clutch )+base plate+normal/intelligent control panel
The accessories: two wheels or four wheels trailer, silence-box or weather-proof, vacuum assisted system (for increasing the suction lift) etc. can be supplied according to customers' demands.
Application:
1. Air Conditioning 7. Pressure Boosting
2. Fire Protection 8.Cooling Towers
3. Plumbing 9.Irrigation
4.Circulating 10. Water Treatment & Supply
5.Transfer 11.Chemical
6.Sea Water Treatment
Specifications For Pump and Diesel Engine
Pump Type: End Suction Centrifugal Water Pumps
Suction: 50-300mm
Flow rate: 6.3-1080 m3/h
Head: 5-150m
Speed: 1450r/min~ 3500 rpm
Suction ability : wet primining , vacumm system assisted
Max working pressure : 2.5 Mpa
Working temperature : - 10 °c ~ 105°c
Power : Diesel engine or electric motor
Trailer : two wheel or four wheel
Silenbox canpoy : available
Standard : DIN 24255 ; BS EN733 or ISO
Diesel Engine: Cummins, deutz, perkins, lister peter, ricardo, Chinese etc brands engine according to customers' requirements or we recommend
Engine Type: air cooled or water cooled engine
Connection way for pump with engine: pin coupling (hard to hard),high elastic coupling (avoid vibration, can protect the pump set)
Installation: diretly coupling engine mounted, horizontal V-belt type installation, vertical type
Part Material
| Part | Material |
| Pump casing: | cast iron standard, stainless steel optional |
| Impeller: | stainless steel standard, bronze, cast iron optional |
| Shaft: | ASTM420 standard, ASTM304, ASTM316, ASTM1045 optional |
| Shaft seal | Mechanical seal standard |
Application Casing
Plywood Case
Pre-sale
Good pre-sale service is an important guarantee to the customer interest. our professional senior service engineer to provide customers with design plans and consultant, which avoids the unnecessary loss caused by improper operation of customers to the largest extent.
In-sale
Our highly professional service staff continuously provides tracking service, giving instruction to installation, explicating the operation main points and cautions in order to ensure the efficient operation of the product and reduce the breakdowns caused by improper operation of customers to the largest extent.
After-sale
We will check the customers' usage of pump regular positively in order to correct the improper operation of customers in time, carry through the guidance of maintenance in time.
