Home > Construction & Decoration > Slate, Marble, Granite & Stone > Quartz Stone > Quartz Sand Filter For Water Treatment
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
AIGER
Model Number:
A-S
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin&Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Beijing, China
Brand Name
AIGER
Model Number
A-S
Application
sand water filter
Shape
round
Dimensions
S640&S650&S660
Chemical Composition
Quartz sand
Specifications
1.Automatic backwashing2.Easy-to-use
3.Convenient installation
4.Compact size and reasonable
Technical parameters
- Single filter water flow: 50m³/h
- Pressure rating: 0.25Mpa~2.5Mpa
- Working temperature range: 0 ~ 65 °C
- Effluent turbidity:less-than three
- Inlet and outlet Connection: flange
- Backwash water: for total filtered water 1 to 3%
- Control mode: pressure control; PLC timing control;
- Installation: vertical, horizontal
Mode and Specification
| Model | D(mm) | D1(mm) | H(mm) | H1(mm) | weight(Kg) | filter area(m2) | The clean water (m³/h) |
S605 | 300 | 37.5 | 116.5 | 150 | 42 | 0.07 | 2-5.6 |
S610 | 400 | 50 | 1105 | 180 | 45 | 0.12 | 4-9.6 |
S620 | 500 | 25-75 | 1210 | 180 | 47 | 0.2 | 8-16 |
S635 | 625 | 50-100 | 1200 | 180 | 58 | 0.3 | 12-24 |
S640 | 750 | 50-100 | 1070 | 300 | 125 | 0.44 | 17-35 |
S650 | 900 | 50-100 | 1110 | 300 | 197 | 0.63 | 25-50 |
S660 | 1200 | 50-100 | 1110 | 300 | 290 | 1.13 | 45-90 |
Size chart
