Sand Filter Design

Beijing Zhongyuantong Science And Technology Co., Ltd.
5Yrs
Sand Filter Design thumbnail-1
Sand Filter Design photo-1
Negotiable MOQ: 1 Strand (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
AIGER
Model Number:
A-S
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Beijing, China
Brand Name AIGER
Model Number A-S
Type Other, sand filter

Specifications

1.Rigorous design
2.Programmable control
3.Automatic backwashing
4.High efficiency filter

Characteristic description

A-S series Quartz Sand Strainers using quartz sand as filter media in a filter with high efficiency, can effectively remove the suspended substance in water, microorganisms, and other fine as to reduce water turbidity, water purification effect.The system is the automatic system, if without artificial operation, the system will automatically backwashing once every 24H (backwash interval reference number can be based on user conditions to change)



Technical parameters

  • Single filter water flow: 50m³/h
  • Pressure rating: 0.25Mpa~2.5Mpa
  • Working temperature range: 0 ~ 65 °C
  • Effluent turbidity:less-than three
  • Inlet and outlet Connection: flange
  • Backwash water: for total filtered water 1 to 3%
  • Control mode: pressure control; PLC timing control
  • Sewage way: automatic sewage suction nozzle or brush, safe and  reliable
  • Rated operation voltage: 220V, 380V, 50HZ, three-phase
  • Installation: vertical, horizontal

Model and Specification

Model

D(mm)

D1(mm)

H(mm)

H1(mm)

weight(Kg)

filter area(m2)

The clean water

(m³/h)

S605

300

37.5

116.5

150

42

0.07

2-5.6

S610

400

50

1105

180

45

0.12

4-9.6

S620

500

25-75

1210

180

47

0.2

8-16

S635

625

50-100

1200

180

58

0.3

12-24

S640

750

50-100

1070

300

125

0.44

17-35

S650

900

50-100

1110

300

197

0.63

25-50

S660

1200

50-100

1110

300

290

1.13

45-90



Size Chart





Sand filter design



Real figure



Sand filter design
