FULLY AUTOMATIC PP STRAP BAND EXTRUSION MACHINE
PP STRAPPING PRODUCTION LINE
POLYPROPYLENE STRAPS MAKING MACHINERY
1. Specifications
1. Power |
380v/3P/50Hz
|
2. Material |
PP
|
|
3. Extruding capacity NOTE: The extruding capacity may be changed as a result of the processing materials and different process conditions.
|
250kg/hr
|
4. Product specification |
width 5-19mm. thickness 0.35-1.0mm
|
5. Speed |
max.120m/min
|
6. Mid-height of extruder |
1000 mm
|
|
7. Control Direction |
From left to right |
|
8. Total power |
160kw(Energy consumption: Appro.96kw)
|
9. humidity |
<85%
|
10.temperature |
0-40°C
|
11.Cooling cycling water |
<20°C >0.3Mpa ~30T/h
|
peressed air |
0.4m³/min>0.5MPa |
13.Overall dimension |
36m×6m×4.5m (36 meters to be overall dimensions including winders.)
|
2. OUTPUT PARAMETERS EXAMPLE (only for reference)
PP STRAP "EMBOSSED"
Strap width (mm) |
Strap thickness (mm) |
Strap weight (gr/mt) |
No of straps |
Speed (mt/min) |
Production (kg/h) |
5 |
0.5 |
1.6 |
6 |
120 |
70 |
9 |
0.6 |
3.2 |
6 |
120 |
138 |
12 |
0.6 |
5.3 |
6 |
120 |
240 |
15 |
0.6 |
6.6 |
6 |
105 |
250 |
15 |
0.8 |
8.8 |
6 |
78.9 |
250 |
19 |
0.85 |
11.5 |
3 |
120 |
250 |
3. Contact Information
Loyal Luo, Sales Export & Business Developer
CissCo Machinery Co., Ltd.
Mob.: +86 18817937157 I Office: +86 2138726398 / 99
Email: market02@ I Skype: cisscomachine03 I Web:
Add.: 30B, No.58 New Jinqiao Road, Pudong, Shanghai, China
