Flat dripper irrigation tape production machine
1. Technical specification of flat dripper drip irrigation pipe extrusion line
1.1 Pipe Specification:
Pipe diameter |
Specifications |
||
Ø12 |
Ø16 |
Ø20 |
|
Pipe thickness |
0.15-0.4mm |
0.15-0.6 mm |
0.15-0.6 mm |
1.2 Speed:90-180m/min
1.3 Center Height: 1000MM
1.4 Installed power: about 135 kW (High speed model )
1.5 Equipment Layout (L*W*H): 25-28* 4..5*3 meter
2. Configuration of flat dripper drip irrigation pipe extrusion line
NO. |
Name |
Qty. |
1 |
Automatic material machine and Mixed machine |
1set |
2 |
Dropper recognition, transportation and insert machine |
1set |
3 |
SJ60/33 Single screw extruder |
1set |
4 |
Cross die head |
1set |
5 |
Vacuum calibrating tank |
1set |
6 |
Water cooling tank and water removing equipment |
1set |
7 |
Automatic Drilling unit (Perforating unit) |
1set |
8 |
Haul off |
2sets |
9 |
Coiler/winder |
1set |
10 |
PLC system and Electrical Control cabinet |
1set |
3. Pictures of flat dripper drip irrigation pipe extrusion line
- New Flat dripper irrigation pipe production Line ( speed l: 150m/min)
Pipe diameter |
Specifications |
||
Ø12 |
Ø16 |
Ø20 |
|
Pipe thickness |
0.2-0.4 mm |
0.2-0.9mm |
0.2-0.6mm |
Flat Dripper
- Round Drip Irrigation pipe production Line ( speed l: 80m/min)
Pipe diameter |
Specifications |
||
Ø12 |
Ø16 |
Ø20 |
|
Pipe thickness |
0.5-1.0mm |
0.5-1.5 mm |
0.5-1.5 mm |
Column Dripper
- Drip Tape Irrigation Pipe Extrusion Line (speed:. 80-120m/min)
Pipe diameter |
Specifications |
||
Ø12 |
Ø16 |
Ø20 |
|
Pipe thickness |
Depending on |
Customer |
Requirements |
Tape Dripper
CissCo Machinery Co., has been engineering and manufacturing a series of EXTRUSION MACHINERY for more than 20 years and has thus acquired an extensive expertise in the supply of manufacturing machinery; having based ourselves on the features demanded by large companies in more than 30 countries.
Comparing with the low price low quality machine, please note our strong advantages:
1. 20 Years Experiences;
2. European Latest Technology;
3. Easy to Operate, Stable Performance, Good Quality Products, Low Production Cost;
4. Quicker Production Speed, Big Output;
5. Good Material and Well-Known Brand Electrical Parts;
6. Beautiful Appearance;
7. Free Training for Technical Process, Formula and Know-How;
8. Full Time and High Level After-Sale Services.
