China Factory Competitive Price ZS Series Vibrating Rectangular Screening Machine

China Factory Competitive Price ZS Series Vibrating Rectangular Screening Machine photo-1
China Factory Competitive Price ZS Series Vibrating Rectangular Screening Machine photo-2
China Factory Competitive Price ZS Series Vibrating Rectangular Screening Machine photo-3
China Factory Competitive Price ZS Series Vibrating Rectangular Screening Machine photo-4
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Circular
Application:
Other, pharmacetical. chemical and foodstuff, Powder and granulate
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port China(Mainland)
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Circular
Application Other, pharmacetical. chemical and foodstuff, Powder and granulate
Place of Origin Jiangsu, China
Brand Name PF
Model Number ZS Series Vibrating Rectangular Screening Machine
Voltage 380V
Power(W) 0.2-0.75kw
Dimension(L*W*H) 1110*500*900mm
Weight 150-800kg
Certification CE ISO
Warranty 1 Year, 1 year
After-sales Service Provided Engineers available to service machinery overseas

China Factory Competitive Price ZS Series Vibrating Rectangular Screening Machine

Product Description

Main Application

Designed and modified by importing the advanced foreign technology and in combination with GMP standard, this machine is widely used for grading and screening of industrial raw materials in such trades as pharmaceutical, chemical, foodstuff, metallurgy and electronics etc..


Working principle

This machine is comprised of screen box, Vibration source and damper, vibrating frame and screen box are connected with 4-12 group soft rubber dampers fixed up and down, and the centrifugal force is generated therein, the floating amplitude is controlled by the damper, by which, material realizes a process of throw and lamination filtration downward, and therefore reaching the optimized grading and screening effect.



Technical parameters



l Production capacity Meshes screened Motor power Vibration frequency Exciting force  Overall dimension Weight
ZS-0.3m2 50-300kg/h 3-150mesh 0.2kw 1400r/min 0-2.5kw 1110*500*900mm 150kg
ZS-0.5m2 100-450kg/h 3-150mesh 0.2kw 1400r/min 0-2.5kw 1250*660*900mm 250kg
ZS-0.m2 200-650kg/h 3-150mesh 0.2×2kw 1400r/min 0-2.5kw 1780*650*960mm 280kg
ZS-0.8m2 300-750kg/h 3-150mesh 0.3kw 1400r/min 0-2.5kw 1500*800*900mm 320kg
ZS-1.2m2 500-1100kg/h 3-150mesh 0.5kw 1400r/min 0-2.5kw 1980*1050*1450mm 400kg
ZS-1.8m2 800-1600kg/h 3-150mesh 0.75kw 1400r/min 0-2.5kw 2400*1200*1500mm 600kg
ZS-2.2m2 1000-2500kg/h 3-150mesh 0.75kw 1400r/min 0-2.5kw 2800*1200*1600mm 800k
