Forest Working T180F Crawler Bulldozer

Forest Working T180F Crawler Bulldozer thumbnail-1
Forest Working T180F Crawler Bulldozer photo-1
US$ 70,000 - 90,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
SENX
Model Number:
T180F
Contact Supplier Request Quote Chat Now
Shandong Senxin Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI TIANJIN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name SENX
Model Number T180F
Condition New
Moving Type Crawler Bulldozer
Machine Weight 17900kg
Dimension(Long * Breadth * High) 5360x3970x3063mm
After-sales Service Provided Overseas third-party support available

Quick Details

  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: SENX
  • Model Number: T180F
  • Condition: New
  • Moving Type: Crawler Bulldozer
  • Machine Weight: 17900kg
  • Dimension(Long * Breadth * High):5360x3970x3063
  • After-sales Service Provided: Overseas third-party support available
  • Item: T180F Bulldozer for sale
  • Track rollers: 7/each side
  • Track type: Sealed,assemled single-grouser
  • Number of track shoes: 39(each side)
  • Width of track shoes: 510 mm
  • Pitch: 203 mm
  • Length of track on the ground: 2635 mm
  • Engine: Shangchai/weichai/NT855
  • Operating weight: 17900 kg( staight-tilt)
  • Blade capacity: 4.5 cbm




Product Description

Item name :  Forest working T180F Crawler bulldozer for sale ,winch optional .



Operating weight :17900KGS



Engine : SHANGCHAI / WEICHAI / NT855 .



BULLDOZER FOR SALE / SHANTUI BULLDOZER / CHINESE BULLDOZER





T180F       BULLDOZER
    AWARDED THE ISO9001:2000 SYSTEM CERTIFICATE
SPECIFICATION
Specification/Blade type        Straight-tilt    Angle      U-Blade
Operating Weight (kg)           17900          18200       18500
Min.Ground Clearance (mm)  400             400              400
Min.Turning Radius (m)             3.3            3.3               3.3
Ground Pressure (MPa)         0.065          0.066       0.066
Track Gauge (mm)                    1880         1880            1880
Track Gauge (mm)                  147.2         147.2           147.2
Grade Ability (°)                            30            30                 30
TRAVEL SPEED
                    1st      2nd     3rd      4th     5th
Forward (km)               2.6            3.5           4.7             7.0        10.3
Reverse (km)             3.3            4.5            6.1             9.1
ENGINE
Model & Type...............Cummins NT855-C280S10/ Shangchai SC11CB200G2B1/ Weichai WD10G200E25, 6-cylinder, in-line, vertical. water-cooled, 4-stroke-cycle, turbo-charged, over valve directs injection
Rated Revolution (rpm) ......................................................... 1850
Flywheel Horsepower (HP) .................................................... 180
                                                                    Cummins:6-139.7X152.4
Cylinder Number-BoreX Stroke (mm) Shangchai:6-120.6X152.4
                                                                    Weichai:6-126X130
Piston Displacement (L)                                                      Cummins:14            Shangchai:10.5         Weichai:9.73
Min. Fuel Consumption (g/kW.h)........................Cummins:212       Shangchai:220      Weichai:218
Max.Torque (Nm/rpm).................................Cummins:877/1250   Shangchai:870/1200  Weichai: 920/1100
Starting Method....................................Starting motor  24V  7.5kW
TRANSMISSION SYSTEM
Main Cluch.................. Wet , multiple-disc, with cut-off brake. hand-manipulated and hydraulic boosted
Transmission.................. Bevel gear, constant meshed, forced lubrication, hand-manipulated,5 forward and 4 reverse speeds
Bevel Gear.....................Spiral bevel gear, splash lubrication, single-stage speed reduction
Steering Clutch......... Wet, multi-disc, spring loaded,hydraulically separated, hydraulic control
Steering............Brake Wet, band type, pedal hydraulic booster, with parking brakes
Final Drive...... Double reduction of spur gear, splash lubrication
HYDRAULIC SYSTEM
Pump Type................................................Gear pump 07441-67503
Working Pressure (MPa)..............................................................13.7
System Discharge (L/min)............ 250(at revolution of 1850rpm)
Working Cylinder type........................... Double-acting piston type
Working Cylinder Lift Number-BoreXRodXStroke (mm)................            2-110X65X1026
Working Cylinder Tilt BoreXRodXStroke (mm).........160X70X140
