Specifications
1. High Capacity2. Energy Saving
3. Professional Technical
4. Export More than 30 Countrys
Rotary Dryer
Skype: zkbm1998
Rotary Dryer Brief Introduction:
This Rotary Dryer is suitable for manure of chicken, ducks, livestock waste, and slaughtering
scraps, etc, which contains less than 65% water, having good effect on opening up feed resources,
reducing the cost of feed and reducing environmental pollution.The manure dryer adopts the way
of airflow drying, with high thermal efficiency. Under the premise of not destroy the quality of the
finished product, it achieve deodorization and killing insects sterilization for the materials. The dryer
can dry the materials containing much water to below 14% in the end.
Rotary Dryer Work Principle:
Conveyed from the feed screw directly into the dryer drum, raised by the drum wall panels repeatedly,
and scattered by the crushing blow dispersion devices, materials and the negative hightemp media are
combined sufficiently to complete heat and mass transfer process. Because of the influence of the
roller angle and the induced draft fan, the material move slowly from the inlet side to the outlet side,
then they are discharged by the airflow in the outlet side, after further drying by the pipeline, the material
enter into the dust catcher, finally shut out from the air seal machinery.
Main Technical Parameters:
Model |
Gradient (°) |
Speed (R/min) |
Volume (m³ ) |
Power (kw) |
Capacity (t/h) |
Weight (t) |
|
Φ0.6×8m
|
3-5 |
8 |
2.26 |
4 |
1-3 |
2.9 |
|
Φ0.8×10 m
|
3-5 |
7.2 |
5.02 |
4 |
4-6 |
4.5 |
|
Φ1.0×10 m
|
3-5 |
6.73 |
7.85 |
5.5 |
5-8 |
5.6 |
|
Φ1.2×12 m
|
3-5 |
5.8 |
13.31 |
11 |
8-12 |
14.8 |
|
Φ1.5×12 m
|
3-5 |
4.8 |
21.2 |
15 |
10-15 |
17.8 |
|
Φ1.8×14 m
|
3-5 |
3.2 |
48.22 |
30 |
12-18 |
27 |
Φ2.2×18 m |
3-5 |
3 |
70.43 |
37 |
15-20 |
53.8 |
|
Φ2.4×20 m
|
3-5 |
2.83 |
90.43 |
45 |
20-25 |
60 |
|
Φ2.8×24 m
|
3-5 |
2.59 |
147.8 |
75 |
25-30 |
67 |
|
Φ3×20 m
|
3-5 |
1.5-5 |
141.3 |
55 |
25-35 |
78 |
|
Φ3×25 m
|
3-5 |
1.5-5 |
176.6 |
75 |
32-40 |
104 |
