What is Factory Price XY 2 Water Bore Well Drilling Rig Machine for Sale
Factory Price XY 2 Water Bore Well Drilling Rig Machine for Sale:
1. XY 2 Water Well Drilling Rig Machine used for the general exploration and investigation of solid mineral deposit, engineering geotectonic survey and concrete structure inspection holes.
2.Diamond drill bit, alloy drill bit and steel roller drill bit and so on are available for drilling according to different geological structures.
3.When the final holes are respectively 75mm and 46mm in diameter, the rated hole depths are separately 100m and 180m. The maximum of depth may not exceed 110% of that drilled in each hole. The maximum allowable hole diameter is 150 mm.
Features of Factory Price XY 2 Water Bore Well Drilling Rig Machine for Sale
1.With hydraulic feeding device, elevated drilling efficiency, reduced labor strength.
2.The XY 2 Water Well Drilling Rig Machine is equipped with an upper spherical jaw holding mechanism and hexagonal drive drilling rod which can be replaced without shutdown, high efficiency, safe and reliable.
3. A hole bottom pressure gauge is mounted indicating the pressure in order to control the status inside the hole.
4.Compact structure, small volume, lightweight, high detachability, easy transportation and suitable for the operations in plains or mountain areas.
Sprcifications of Factory Price XY 2 Water Bore Well Drilling Rig Machine for Sale
Drilling capacity(m) | 73 rod | 100 |
60 rod | 200 | |
50 rod | 380 | |
42 rod | 530 | |
|
| 65;114;180;248; |
Reverse | 51;242 | |
Max torque (Nm) | 2760 | |
Angle reange | 0-90° | |
Spindle max pull force(KN) | 60 | |
Spindle stroke (mm) | 600 | |
Hoist max life capacity with single rope (KN) | 30 | |
Spindle inner dia (mm) | 76 | |
Oil pump | SCB32/12 | |
Power unit | Electric motor | Y180L-4,22Kw |
Diesel engine | 395K2,19.85Kw | |
| 2150×900×1690 | |
Drill body weight (excluding power)(kg) | 950 | |
Pictures of Factory Price XY 2 Water Bore Well Drilling Rig Machine for Sale
