What is 150m China Manufacturer Water Well Borehole Drilling Rig.
150m China Manufacturer Water Well Borehole Drilling Rig
1. Power can be electrical motor or diesel engine, as per your project needs;
2. Engine and Mud pump, reduction gears and Drill rig are all installed on one base, more compact structure and improve the overall rigidity;
3. Mounted in 2-wheel trailer, easy to move around when working;
4. Easy to disassemble, installed and operation,
the Heaviest part is less than 100KG, convenient for maintenance and transport;
5. Using alloy bit for soft ground,using diamond bits for hard ground
Sprcifications of 150m China Manufacturer Water Well Borehole Drilling Rig
1.Overall parameters | |
Drilling depth | 150m |
Borehole Diameter | 400~75mm |
Diameter of drill rod | 50mm |
Drilling angle | 90~75° |
Weight(not include power) | 760kg |
Dimension | 2000*1000*1400mm |
2. Vertical Spindle | |
Rotating speed | 140,295, 470,790,1010 r/min |
Feeding stroke | 450mm |
Max. Feeding force of spindle | 15 KN |
Max. Lifting capability of spindle | 25 KN |
Max. Torque | 0.5 KN.m |
3.Hoist | |
Max. single line hoisting capacity | 1600Kg |
Diameter of wire rope | 12mm |
Volume of winding drum | 35m |
Hug floodgate caliber | 245mm |
Hug floodgate belt width | 70mm |
4.Mud pump | |
Type | Horizontal single urn twin-action |
Rate of flow | 95/77 L/min |
MAX. pressure | 1.2MPa |
Working pressure | 0.7MPa |
5.Power (either-or choice) | |
Diesel engine ZS1115 | 18HP, 2200r/min |
Electrical motor Y-160-4 | 11KW, 1460r/min |
Pictures of 150m China Manufacturer Water Well Borehole Drilling Rig
