XY-2B Portable Shallow Water Well Drilling Equipment

Shandong China Coal Industrial & Mining Supplies Group Co., Ltd.
XY-2B Portable Shallow Water Well Drilling Equipment thumbnail-1
XY-2B Portable Shallow Water Well Drilling Equipment thumbnail-2
XY-2B Portable Shallow Water Well Drilling Equipment thumbnail-3
XY-2B Portable Shallow Water Well Drilling Equipment thumbnail-4
XY-2B Portable Shallow Water Well Drilling Equipment thumbnail-5
XY-2B Portable Shallow Water Well Drilling Equipment thumbnail-6
XY-2B Portable Shallow Water Well Drilling Equipment photo-1
XY-2B Portable Shallow Water Well Drilling Equipment photo-2
XY-2B Portable Shallow Water Well Drilling Equipment photo-3
XY-2B Portable Shallow Water Well Drilling Equipment photo-4
XY-2B Portable Shallow Water Well Drilling Equipment photo-5
XY-2B Portable Shallow Water Well Drilling Equipment photo-6
US$ 6,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao shanghai tianjin ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rotary Drilling Rig
Power Type Diesel
Place of Origin Shandong, China
Brand Name China Coal
Model Number XY-2B
Usage Other, core drill
Voltage 380V
Power(W) differ
Dimension(L*W*H) differ
Weight differ
Certification ISO,CE,SGS,TUV,BV
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description



What is XY-2B Portable Shallow Water Well Drilling Equipment

XY-2B Portable Shallow Water Well Drilling Equipment

XY-2B Portable Shallow Water Well Drilling Equipment derived from xy-2 drill rig, it not only keeps all performances of xy-2 drill, but also adds spindle inner hole diameter to 96mm. It is especially available for constructions of hydroelectric power station, highway, railroad and harbor etc. In common with xy-2 drill in all design but hydraulic chuck and rotary head modified.

Sprcifications of XY-2B Portable Shallow Water Well Drilling Equipment








Drilling capacity (m)







 BQ rod

 400-550



 NQ rod

 350-500



 HQ rod

 250-300



73 rod

100



60 rod

200



50 rod

380



42 rod

530


Spindle speed(r/min)

 Forward

57;99;157;217;270;470;742;1024



 Reverse

45;212


Max torque(Nm)

2760


Angle renge

0-90°


Spindle max pull force(KN)

60


Spindle stroke (mm)

600


Hoist max lift capacity with single rope (KN)

30


Spindle inner dia (mm)

76


Oil pump

SCB32/12


Power unit


Electric motor

Y180L-4,22Kw




Diesel engine

395K2,19.85Kw


Inner dia of spindle (mm)

2150×900×1690


Drill weight(excluding power)(kg)

950



Pictures of XY-2B Portable Shallow Water Well Drilling Equipment

XY-2B Portable Shallow Water Well Drilling EquipmentXY-2B Portable Shallow Water Well Drilling EquipmentXY-2B Portable Shallow Water Well Drilling Equipment
