Home > Manufacturing & Processing Machinery > Machine Tools > Lathe > High Speed Precision CNC Turning Lathe Machine CB45

High Speed Precision CNC Turning Lathe Machine CB45

Name: High Speed Precision CNC Turning Lathe Machine CB45
Brand: xiashi
SKU: 140990430
Availability: InStock

High Speed Precision CNC Turning Lathe Machine CB45 thumbnail-1

High Speed Precision CNC Turning Lathe Machine CB45 thumbnail-2

High Speed Precision CNC Turning Lathe Machine CB45 photo-1

High Speed Precision CNC Turning Lathe Machine CB45 photo-2

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Guangxi Xiashi Machinery Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 320mm

Place of Origin Guangxi, China

Brand Name xiashi

Model Number CB45

Voltage 380V/50Hz

Power(W) 1.5kw

Dimension(L*W*H) 2020*1485*1760mm

Weight 2500kg

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Introduction

This efficient CNC lathe is capable of cylindrical, tapered and stepped turning, end facing, hole drilling, gooving, circular surface cutting, cylindrical and tapered Metric and Inch thread cutting.

It features with linear ways and series collet chuck, and is used widely in instrument and light industries, electronic and medical appliance industries, film appliance industry for single work

batch production. It is ideal for non ferrous metal workpieces, small sized workpieces and

complex shaped shaft type and chucked type workpieces machining as well as teaching aid in

college.

Technical parameter

Description		Unit	CB35A
Capacity	Max. swing over bed	mm	Φ320
	Max. swing over slide	mm	Φ120
	Max. turning diameter	mm	Φ120
	Max. turning length	mm	150
	Slant angle of bed		45°
Spindle	Spindle bore	mm	Φ56
	Spindle nose		A2-5
	Bar diameter to be held	mm	Φ45
	Spindle speeds	r/min	4000
Drive of two axes	X-axis motor	kW	1.5
	X-axis rapid traverse	m/min	20
	Z-axis motor	kW	1.5
	Z-axis rapid traverse	m/min	20
	X-axis travel	mm	350
	Z-axis travel	mm	220
Tool rest	Turret type		Comb type
	Section of turning tool	mm	20X20
	Diameter of boring bar	mm	Φ25
Others	Power supply	kVA	10
	Gross weight of machine	kG	2500
	Overall dimension of machien	mm	2020×1485×1760

Detailed pictures for your reference

If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
