Home > Industrial Equipment & Components > Welding Equipment > Resistance Welder > Copper Tube and Aluminum Resistance Welding Machine
US$ 9,000 - 15,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
BOBO
Model Number:
TL-25KW
Payment & Shipping
Payment Methods:
Port of Shipment:
GUANGZHOU
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Steel Wire Straightening and Cutting MachineUS$ 3,000 - 5,000MOQ: 1 Set -
Condenser Tube Flaring MachineUS$ 1,700 - 2,000MOQ: 1 Set
-
Condenser Tube Expanding MachineUS$ 2,000 - 2,500MOQ: 1 Set
-
Six Cylinders Condenser And Evaporator Welding MachineUS$ 15,000 - 25,000MOQ: 1 Set
-
Six Cylinders Multi-points Semi-auto Condenser And Evaporator Welding MachineUS$ 15,000 - 18,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
BOBO
Model Number
TL-25KW
Primary Voltage
380V
Rated Duty Cycle
50%
Rated Capacity
25KVA
Dimensions
1520*800*500mm
Usage
Welding the evaporator tube, air cnditioning tube joints
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Copper tube and aluminum tube resistance welding machine:1- Product pass rage is reach 99.9%
2-Save raw material
Product Description
COPPER TUBE AND ALUMINUM TUBE RESISTANCE WELDING MACHINE
The copper tube and aluminum tube resistance welding machine is suitable for air conditioning, refrigerator etc refrigeration enterprise. Based on 20 years more experience, we develop “correcting force freely adjust” new type plug-in resistance welding machine.
FEATURES:
- By Uprighting force free calibration device can quickly adjust concentricity of welding machine, save the adjusting time and raw material;
- The electrical equipment of this machine has high anti-interference capability. The power instability will affect the welding quality.
- Adopting adjustable transformer, from grade 1 to grade 8 is adjustable, can according to the diameter of tube and power voltage to adjust, in order to achieve the best welding effect.
TECHNICAL DATA:
Model | Diameter | Power | Adjust Level of Output Voltage | Air pressure |
TL-25KVA | Φ4~Φ8 | 380V/50Hz | 8 Level | 0.6~0.8MPa |
TL-50KVA | Φ8~Φ15 | |||
TL-75KVA | Φ8~Φ19 | |||
TL-100KVA | Φ10~Φ26 |
Packaging & Shipping
1-Packing: professional export wooden box
2-Shipping:LCL/FCL, we have professional shipping department coordinate with customers on orders
Our Services
1-Customized accordingly
2-Professional after service department
3-Testing service
